Product Description
With a 20-ton working weight and a robust QSB7 engine, this 2017 XCMG XE200DA excavator is a reliable choice for your construction needs. Made in China, XCMG machinery is known for its durability and parts availability, making it a safe investment in the used market. Featuring a 0.93 m³ bucket capacity and a maximum digging depth of 6460 mm, this model ensures efficient performance on any job site.
- Rated power: 135 kW at 2050 rpm
- Maximum torque: 740 N.m at 1250 rpm
- Travel speed: 5.3 km/h (high), 2.9 km/h (low)
- Fuel tank: 400 L
- Total transport dimensions: 9625 mm x 2900 mm x 3100 mm
Boasting a strong resale value, this XCMG excavator is equipped with a backhoe bucket and offers a climbing ability of 35%, ensuring versatility and reliability. Trust in XCMG's global reputation for quality and support to keep your operations running smoothly.
| Specifications | Value |
|---|---|
| No. | 1001078 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21200 |
| Bucket capacity (m³) | 0.93 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2710 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | QSB7 |
| Rated power (kw/rpm) | 135/2050 |
| Maximum torque (N.m) | 740/1250 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.7 |
| Ground specific pressure (Kpa) | 46.9 |
| Rotation speed (rpm) | 11.6 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 149 |
| Rod digging force (kN) | 121 |
| Maximum tractive force (kN) | 184 |
| Travel speed (km/h) | 5.3/2.9 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 220 |
| Engine Oil changes (L) | 24 |
| Total transport length (mm) | 9625 |
| Total transport width (mm) | 2900 |
| Total transport height (mm) | 3100 |
| Counterweight ground clearance (mm) | 1050 |
| Minimum ground clearance (mm) | 486 |
| Maximum digging radius (mm) | 9790 |
| Maximum digging depth (mm) | 6460 |
| Maximum excavation height (mm) | 9680 |
| Maximum unloading height (mm) | 6815 |
| Maximum vertical digging depth (mm) | 5590 |
