Product Description
With a working weight of 21,200 kg and a bucket capacity of 0.93 m³, the XCMG XE200DA excavator is an ideal addition to any contractor's fleet. Made in China, this 20-ton machine features a QSB7 engine, delivering 135 kW at 2050 rpm. Its robust design includes a 6-cylinder, 6.7-liter displacement engine, ensuring reliable performance on demanding jobsites.
- Maximum digging depth: 6460 mm
- Maximum unloading height: 6815 mm
- Travel speed: 5.3/2.9 km/h
- Fuel tank capacity: 400 L
- Hydraulic tank: 220 L
Equipped with a backhoe bucket and a boom length of 5680 mm, this excavator offers versatility and efficiency. The XE200DA is perfect for contractors looking to expand their fleet or add a reliable backup unit, capable of handling a variety of tasks with ease. Located in Jiangxi, this 2018 model is ready to integrate into your operations and enhance productivity.
| Specifications | Value |
|---|---|
| No. | 1019978 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21200 |
| Bucket capacity (m³) | 0.93 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2710 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | QSB7 |
| Rated power (kw/rpm) | 135/2050 |
| Maximum torque (N.m) | 740/1250 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.7 |
| Ground specific pressure (Kpa) | 46.9 |
| Rotation speed (rpm) | 11.6 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 149 |
| Rod digging force (kN) | 121 |
| Maximum tractive force (kN) | 184 |
| Travel speed (km/h) | 5.3/2.9 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 220 |
| Engine Oil changes (L) | 24 |
| Total transport length (mm) | 9625 |
| Total transport width (mm) | 2900 |
| Total transport height (mm) | 3100 |
| Counterweight ground clearance (mm) | 1050 |
| Minimum ground clearance (mm) | 486 |
| Maximum digging radius (mm) | 9790 |
| Maximum digging depth (mm) | 6460 |
| Maximum excavation height (mm) | 9680 |
| Maximum unloading height (mm) | 6815 |
| Maximum vertical digging depth (mm) | 5590 |
