2019 XCMG XE200DA

1/6
Buy XCMG XE200DA Used Excavator / 1
Buy XCMG XE200DA Used Excavator / 2
Buy XCMG XE200DA Used Excavator / 3
Buy XCMG XE200DA Used Excavator / 4
Buy XCMG XE200DA Used Excavator / 5
Buy XCMG XE200DA Used Excavator / 6

Product Description

Built for serious ground work, this 2019 XCMG XE200DA 20-ton excavator is available now in Jiangxi, China — inspected, site-ready, and primed for immediate deployment. Powered by a Cummins QSB7 6-cylinder engine producing 135 kW at 2050 rpm with 740 N·m of peak torque, it delivers the muscle needed for deep excavation, structural demolition, and precision grading without hesitation.

  • Bucket digging force: 149 kN — cuts through compacted soil and rock with authority
  • Maximum digging depth: 6,460 mm — handles deep trenching and foundation work
  • Maximum digging radius: 9,790 mm — wide reach for bulk material handling
  • Maximum unloading height: 6,815 mm — loads trucks and hoppers efficiently
  • Travel speed: 5.3 / 2.9 km/h — moves confidently across active job sites
  • Climbing ability: 35% — performs on slopes and uneven terrain
  • Fuel tank: 400 L — extended run time between refuels on long shifts
  • Operating weight: 21,200 kg — stable platform for high-force digging cycles

With a 0.93 m³ backhoe bucket, 6.7 L displacement, and a ground pressure of just 46.9 kPa, this machine balances raw digging performance with surface protection. Transport dimensions of 9,625 × 2,900 × 3,100 mm keep logistics straightforward. A proven workhorse ready to move dirt from day one.

SpecificationsValue
No.1072713
Tonnage (tons)20
Working weight (kg)21200
Bucket capacity (m³)0.93
Boom length (mm)5680
Rod length (mm)2710
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeQSB7
Rated power (kw/rpm)135/2050
Maximum torque (N.m)740/1250
Number of cylinders (PCS)6
Displacement (L)6.7
Ground specific pressure (Kpa)46.9
Rotation speed (rpm)11.6
Climbing ability (%)35
Bucket digging force (kN)149
Rod digging force (kN)121
Maximum tractive force (kN)184
Travel speed (km/h)5.3/2.9
Fuel Tank (L)400
Hydraulic Tank (L)220
Engine Oil changes (L)24
Total transport length (mm)9625
Total transport width (mm)2900
Total transport height (mm)3100
Counterweight ground clearance (mm)1050
Minimum ground clearance (mm)486
Maximum digging radius (mm)9790
Maximum digging depth (mm)6460
Maximum excavation height (mm)9680
Maximum unloading height (mm)6815
Maximum vertical digging depth (mm)5590
see more

Overview

No.1072713

Brand Name:

XCMG

Model Number:

XE200DA

Year:

2019

Location:

Jiangxi China
