Product Description
Equipped with a QSB7 engine, the XCMG XE200DA delivers 135 kW of power at 2050 rpm, ensuring robust performance and reliability. Featuring a 6-cylinder, 6.7-liter displacement, this excavator provides a maximum torque of 740 N.m at 1250 rpm. The hydraulic system is designed for precision and efficiency, with a bucket capacity of 0.93 m³ and a digging force of 149 kN, making it ideal for demanding tasks.
- Working weight: 21,200 kg
- Boom length: 5,680 mm
- Rod length: 2,710 mm
- Maximum travel speed: 5.3 km/h (high), 2.9 km/h (low)
- Fuel tank capacity: 400 L
- Hydraulic tank capacity: 220 L
- Ground specific pressure: 46.9 Kpa
Engineered in China, the XE200DA boasts a climbing ability of 35% and a maximum tractive force of 184 kN, enhancing its versatility across various terrains. With a total transport length of 9,625 mm, width of 2,900 mm, and height of 3,100 mm, this model is designed for easy transportation and maneuverability on-site.
| Specifications | Value |
|---|---|
| No. | 1033495 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21200 |
| Bucket capacity (m³) | 0.93 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2710 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | QSB7 |
| Rated power (kw/rpm) | 135/2050 |
| Maximum torque (N.m) | 740/1250 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.7 |
| Ground specific pressure (Kpa) | 46.9 |
| Rotation speed (rpm) | 11.6 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 149 |
| Rod digging force (kN) | 121 |
| Maximum tractive force (kN) | 184 |
| Travel speed (km/h) | 5.3/2.9 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 220 |
| Engine Oil changes (L) | 24 |
| Total transport length (mm) | 9625 |
| Total transport width (mm) | 2900 |
| Total transport height (mm) | 3100 |
| Counterweight ground clearance (mm) | 1050 |
| Minimum ground clearance (mm) | 486 |
| Maximum digging radius (mm) | 9790 |
| Maximum digging depth (mm) | 6460 |
| Maximum excavation height (mm) | 9680 |
| Maximum unloading height (mm) | 6815 |
| Maximum vertical digging depth (mm) | 5590 |
