Product Description
Built for contractors who can't afford downtime, this 2021 XCMG XE200DA 20-ton excavator is ready to step in as a dependable fleet addition or high-performance backup unit. Powered by a Cummins QSB7 six-cylinder engine producing 135 kW at 2050 rpm and 740 N·m of peak torque, it delivers consistent output across demanding dig cycles without burning through your fuel budget — the 400L tank keeps it running long shifts between refills.
Currently located in Fujian, China, this machine is well-positioned for export to Southeast Asia, the Middle East, or beyond. With a maximum digging depth of 6,460 mm, a bucket digging force of 149 kN, and a maximum digging radius of 9,790 mm, it handles foundation work, trenching, and bulk earthmoving without hesitation.
- Working weight: 21,200 kg | Bucket capacity: 0.93 m³
- Max digging depth: 6,460 mm | Max digging radius: 9,790 mm
- Bucket digging force: 149 kN | Rod digging force: 121 kN
- Rated power: 135 kW / 2050 rpm (Cummins QSB7, 6.7L displacement)
- Max tractive force: 184 kN | Travel speed: 5.3 / 2.9 km/h
- Ground pressure: 46.9 kPa | Climbing ability: 35%
- Transport dimensions: 9,625 × 2,900 × 3,100 mm
- Fuel tank: 400L | Hydraulic tank: 220L
For fleet managers expanding capacity or replacing aging iron, this XE200DA offers proven XCMG build quality at a competitive price point. Contact us for inspection reports, shipping quotes, and availability.
| Specifications | Value |
|---|---|
| No. | 1085060 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21200 |
| Bucket capacity (m³) | 0.93 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2710 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | QSB7 |
| Rated power (kw/rpm) | 135/2050 |
| Maximum torque (N.m) | 740/1250 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.7 |
| Ground specific pressure (Kpa) | 46.9 |
| Rotation speed (rpm) | 11.6 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 149 |
| Rod digging force (kN) | 121 |
| Maximum tractive force (kN) | 184 |
| Travel speed (km/h) | 5.3/2.9 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 220 |
| Engine Oil changes (L) | 24 |
| Total transport length (mm) | 9625 |
| Total transport width (mm) | 2900 |
| Total transport height (mm) | 3100 |
| Counterweight ground clearance (mm) | 1050 |
| Minimum ground clearance (mm) | 486 |
| Maximum digging radius (mm) | 9790 |
| Maximum digging depth (mm) | 6460 |
| Maximum excavation height (mm) | 9680 |
| Maximum unloading height (mm) | 6815 |
| Maximum vertical digging depth (mm) | 5590 |
