Product Description
With a working weight of 21,500 kg and a bucket capacity ranging from 1.0 to 1.2 m³, the 2020 XCMG XE205DA excavator offers high performance at a fraction of the cost of new equipment. Located in Sichuan, Luzhou, this machine is powered by a QSB7 engine, delivering 135 kW at 2050 rpm, ensuring reliable and efficient operation. Equipped with a backhoe bucket, it provides robust digging forces of 157 kN for the bucket and 116 kN for the rod, making it ideal for demanding construction projects. The XE205DA also features a 4-stroke, turbocharged, water-cooled engine, enhancing its durability and operational efficiency. Traveling at speeds up to 5.7 km/h, this excavator combines versatility with mobility. Invest wisely in this used XCMG model, which retains the quality and reliability of a leading Chinese manufacturer, providing a smart, cost-effective solution for your heavy machinery needs.
| Specifications | Value |
|---|---|
| No. | 1020866 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 1.0-1.2 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2910 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | QSB7 |
| Rated power (kw/rpm) | 135/2050 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.7 |
| Working form | Direct injection, 4-stroke, turbocharged, air-to-air cold |
| Ground specific pressure (Kpa) | 47.5 |
| Rotation speed (rpm) | 12 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 157 |
| Rod digging force (kN) | 116 |
| Maximum tractive force (kN) | 184 |
| Travel speed (km/h) | 5.7/3.1 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 220 |
| Engine Oil changes (L) | 24 |
| Total transport length (mm) | 9630 |
| Total transport width (mm) | 2910 |
| Total transport height (mm) | 3100 |
| Counterweight ground clearance (mm) | 1050 |
| Minimum ground clearance (mm) | 486 |
| Minimum turning radius of front working device (mm) | 3530 |
| Back end turning radius (mm) | 2890 |
| Total track length (mm) | 4155 |
| Track gauge (mm) | 2290 |
| Total track width (mm) | 600 |
| Maximum digging radius (mm) | 9760 |
| Maximum digging depth (mm) | 6660 |
| Maximum excavation height (mm) | 9540 |
| Maximum unloading height (mm) | 6780 |
| Maximum vertical digging depth (mm) | 6480 |
