Product Description
Built in 2020, this XCMG XE205DA excavator delivers proven performance backed by one of China's most established heavy equipment manufacturers. Operating at 20 tons with a robust 135kW QSB7 engine, this machine combines reliable power with practical specifications designed for demanding jobsites. The 5680mm boom and 2910mm arm provide a maximum digging reach of 9760mm and depth of 6660mm, while the 1.0-1.2m³ bucket capacity ensures productive material handling across diverse applications.
XCMG's global distribution network means parts availability and service support remain accessible long after purchase, protecting your investment in the used market. With 157kN bucket digging force and 184kN maximum tractive force, this XE205DA handles tough excavation tasks with confidence. Water-cooled 6-cylinder engine, 400L fuel capacity, and proven hydraulic systems deliver consistent uptime. Currently located in Shandong, this excavator represents smart value for operators seeking dependable equipment from a manufacturer known for strong resale retention and widespread dealer support across international markets.
| Specifications | Value |
|---|---|
| No. | 1030697 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 1.0-1.2 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2910 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | QSB7 |
| Rated power (kw/rpm) | 135/2050 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.7 |
| Working form | Direct injection, 4-stroke, turbocharged, air-to-air cold |
| Ground specific pressure (Kpa) | 47.5 |
| Rotation speed (rpm) | 12 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 157 |
| Rod digging force (kN) | 116 |
| Maximum tractive force (kN) | 184 |
| Travel speed (km/h) | 5.7/3.1 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 220 |
| Engine Oil changes (L) | 24 |
| Total transport length (mm) | 9630 |
| Total transport width (mm) | 2910 |
| Total transport height (mm) | 3100 |
| Counterweight ground clearance (mm) | 1050 |
| Minimum ground clearance (mm) | 486 |
| Minimum turning radius of front working device (mm) | 3530 |
| Back end turning radius (mm) | 2890 |
| Total track length (mm) | 4155 |
| Track gauge (mm) | 2290 |
| Total track width (mm) | 600 |
| Maximum digging radius (mm) | 9760 |
| Maximum digging depth (mm) | 6660 |
| Maximum excavation height (mm) | 9540 |
| Maximum unloading height (mm) | 6780 |
| Maximum vertical digging depth (mm) | 6480 |
