Product Description
This 2020 XCMG XE205DA hydraulic excavator offers reliable performance for medium-duty construction and earthmoving applications. As a well-maintained unit from XCMG's popular 20-ton class, this machine demonstrates solid operational capability with competitive pricing for budget-conscious contractors and fleet operators.
Currently located in Guangxi, China, this excavator is available for immediate inspection and acquisition. The XE205DA series is recognized for its fuel efficiency, robust hydraulic system, and operator comfort in demanding work environments.
- Year of Manufacture: 2020
- Model: XCMG XE205DA
- Operating Weight Class: Approximately 20 tons
- Current Location: Guangxi Province, China
- Condition: Performance-verified, ready for deployment
This competitively priced unit represents an excellent opportunity for operators seeking proven Chinese manufacturing quality. Contact us for detailed specifications, current condition reports, and export assistance.
| Specifications | Value |
|---|---|
| No. | 1114773 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 1.0-1.2 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2910 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | QSB7 |
| Rated power (kw/rpm) | 135/2050 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.7 |
| Working form | Direct injection, 4-stroke, turbocharged, air-to-air cold |
| Ground specific pressure (Kpa) | 47.5 |
| Rotation speed (rpm) | 12 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 157 |
| Rod digging force (kN) | 116 |
| Maximum tractive force (kN) | 184 |
| Travel speed (km/h) | 5.7/3.1 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 220 |
| Engine Oil changes (L) | 24 |
| Total transport length (mm) | 9630 |
| Total transport width (mm) | 2910 |
| Total transport height (mm) | 3100 |
| Counterweight ground clearance (mm) | 1050 |
| Minimum ground clearance (mm) | 486 |
| Minimum turning radius of front working device (mm) | 3530 |
| Back end turning radius (mm) | 2890 |
| Total track length (mm) | 4155 |
| Track gauge (mm) | 2290 |
| Total track width (mm) | 600 |
| Maximum digging radius (mm) | 9760 |
| Maximum digging depth (mm) | 6660 |
| Maximum excavation height (mm) | 9540 |
| Maximum unloading height (mm) | 6780 |
| Maximum vertical digging depth (mm) | 6480 |
