Product Description
This 2021 XCMG XE205DA hydraulic excavator represents a well-maintained mid-size machine ideal for earthmoving operations. Located in Guangxi, China, this unit has accumulated 4,500 operational hours with verified meter readings. The excavator retains its original factory paint, indicating careful handling and minimal wear throughout its service life.
Recently serviced with a comprehensive maintenance overhaul, this machine is inspection-ready in Nanning. The XE205DA is recognized for its robust construction and reliable performance in general earthwork applications, making it suitable for construction sites, excavation projects, and material handling operations.
- Year of Manufacture: 2021
- Operational Hours: 4,500
- Condition: Original Paint, Single-Owner Earthwork Use
- Service Status: Major Maintenance Recently Completed
- Location: Nanning, Guangxi, China
- Availability: Ready for Inspection
| Specifications | Value |
|---|---|
| No. | 1099857 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 1.0-1.2 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2910 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | QSB7 |
| Rated power (kw/rpm) | 135/2050 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.7 |
| Working form | Direct injection, 4-stroke, turbocharged, air-to-air cold |
| Ground specific pressure (Kpa) | 47.5 |
| Rotation speed (rpm) | 12 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 157 |
| Rod digging force (kN) | 116 |
| Maximum tractive force (kN) | 184 |
| Travel speed (km/h) | 5.7/3.1 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 220 |
| Engine Oil changes (L) | 24 |
| Total transport length (mm) | 9630 |
| Total transport width (mm) | 2910 |
| Total transport height (mm) | 3100 |
| Counterweight ground clearance (mm) | 1050 |
| Minimum ground clearance (mm) | 486 |
| Minimum turning radius of front working device (mm) | 3530 |
| Back end turning radius (mm) | 2890 |
| Total track length (mm) | 4155 |
| Track gauge (mm) | 2290 |
| Total track width (mm) | 600 |
| Maximum digging radius (mm) | 9760 |
| Maximum digging depth (mm) | 6660 |
| Maximum excavation height (mm) | 9540 |
| Maximum unloading height (mm) | 6780 |
| Maximum vertical digging depth (mm) | 6480 |
