Product Description
Built for demanding construction environments, this 2014 XCMG XE215C excavator delivers reliable 21-ton performance with exceptional operator control. Powered by a robust ISUZU 6-cylinder engine producing 106.5kW, this machine combines proven hydraulic technology with practical jobsite capabilities.
Operator-focused design ensures maximum productivity through enhanced cabin visibility and intuitive controls. The spacious operator compartment provides clear sightlines to the work area, while responsive hydraulic systems deliver precise bucket and boom control. Dual plunger pumps generate consistent 206 L/min flow rates, enabling smooth operation across varied terrain conditions.
- 21-ton working weight with 0.8-1.0m³ bucket capacity
- 9.9m maximum digging radius and 6.7m digging depth
- 35° climbing ability with 45.5 kPa ground pressure
- 138kN bucket digging force for tough excavation tasks
- Water-cooled ISUZU engine with turbocharging system
Currently located in Guizhou, this XE215C represents solid value for contractors requiring dependable mid-size excavation equipment. Comprehensive hydraulic systems and proven drivetrain components ensure consistent performance in
| Specifications | Value |
|---|---|
| No. | 991390 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 21450 |
| Bucket capacity (m³) | 0.8-1.0 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2910 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | ISUZU BB-6BG1TRP |
| Rated power (kw/rpm) | 106.5/1950 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.494 |
| Working form | turbocharging |
| Ground specific pressure (Kpa) | 45.5 |
| Rotation speed (rpm) | 13.3 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 5.5/3.5 |
| Main overflow set pressure (Mpa) | 31.5/34.3 |
| Maximum flow of main pump (l/min) | 2*206 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 28 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | 2 plunger pumps |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 360 |
| Hydraulic Tank (L) | 220 |
| Engine Oil changes (L) | 25 |
| Total transport length (mm) | 9525 |
| Total transport width (mm) | 2990 |
| Total transport height (mm) | 3000 |
| Counterweight ground clearance (mm) | 1050 |
| Minimum ground clearance (mm) | 470 |
| Minimum turning radius of front working device (mm) | 3530 |
| Back end turning radius (mm) | 2750 |
| Total track length (mm) | 4255 |
| Track gauge (mm) | 2390 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3462 |
| Maximum digging radius (mm) | 9925 |
| Maximum digging depth (mm) | 6655 |
| Maximum excavation height (mm) | 9640 |
| Maximum unloading height (mm) | 6800 |
| Maximum vertical digging depth (mm) | 5695 |
