Product Description
Built to endure the toughest conditions, this 2020 XCMG XE215D excavator represents proven engineering excellence from one of China's leading manufacturers. Operating at 21 tons with a robust 135kW QSB7 engine, this machine delivers consistent performance across demanding jobsites in Guizhou and beyond. With over three years of field-proven reliability, it stands as a testament to XCMG's commitment to durability and longevity.
Engineered for maximum productivity, this workhorse features impressive digging capabilities with 149kN bucket force and 111kN arm force, reaching depths up to 6,680mm and a maximum radius of 9,940mm. The dual plunger pump hydraulic system provides 2 x 225 l/min flow for smooth, powerful operation. Water-cooled turbocharged performance ensures sustained power delivery, while the 400L fuel capacity minimizes downtime on extended shifts.
- Working Weight: 21,900 kg with 0.8-1.3m³ bucket capacity
- Proven Power: QSB7 6-cylinder engine, 740 N.m maximum torque
- Superior Reach: 9,940mm maximum digging radius
- Reliable Hydraulics: 31.5/34.3 MPa main system pressure
- Location: Guizhou, ready for immediate deployment
| Specifications | Value |
|---|---|
| No. | 999841 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 21900 |
| Bucket capacity (m³) | 0.8-1.3 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2910 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | QSB7 |
| Rated power (kw/rpm) | 135/2050 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 740/1250 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.7 |
| Working form | turbocharging |
| Ground specific pressure (Kpa) | 47.2 |
| Rotation speed (rpm) | 11.8 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 149 |
| Rod digging force (kN) | 111 |
| Maximum tractive force (kN) | 184 |
| Travel speed (km/h) | 5.4/3.1 |
| Main overflow set pressure (Mpa) | 31.5/34.3 |
| Maximum flow of main pump (l/min) | 2 x 225 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 27.5 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | 2 plunger pumps |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 220 |
| Engine Oil changes (L) | 19.5 |
| Total transport length (mm) | 9625 |
| Total transport width (mm) | 2990 |
| Total transport height (mm) | 3100 |
| Counterweight ground clearance (mm) | 1050 |
| Minimum ground clearance (mm) | 476 |
| Minimum turning radius of front working device (mm) | 3530 |
| Back end turning radius (mm) | 2890 |
| Onboard width (mm) | 2830 |
| Total track length (mm) | 4255 |
| Track gauge (mm) | 2390 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3462 |
| Maximum digging radius (mm) | 9940 |
| Maximum digging depth (mm) | 6680 |
| Maximum excavation height (mm) | 9620 |
| Maximum unloading height (mm) | 6780 |
| Maximum vertical digging depth (mm) | 5715 |
