Product Description
Built for serious earthmoving, the 2019 XCMG XE215DA is a 21-ton hydraulic excavator ready to move to your site and start working immediately. Powered by a Cummins QSB7 6.7L 6-cylinder turbocharged engine rated at 135 kW / 2050 rpm with water-cooling and electronic fuel injection, this machine delivers consistent, reliable performance across digging, grading, trenching, and demolition applications.
With a bucket digging force of 149 kN, a maximum digging depth of 6,680 mm, and a 1.05 m³ backhoe bucket, this excavator handles high-volume material removal without hesitation. A dual main pump system flowing 2×216 L/min ensures responsive hydraulic output under continuous load.
- Maximum digging radius: 9,940 mm
- Maximum excavation height: 9,620 mm
- Maximum unloading height: 6,780 mm
- Rod digging force: 111 kN
- Maximum tractive force: 184 kN
- Climbing ability: 35%
- Travel speed: 5.4 / 3.1 km/h
- Track plate width: 600 mm | Ground pressure: 47.2 kPa
- Fuel tank: 400 L | Hydraulic tank: 220 L
- Location: Guangdong, China — available for immediate export
| Specifications | Value |
|---|---|
| No. | 1086393 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 21900 |
| Bucket capacity (m³) | 1.05 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2910 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | QSB7 |
| Rated power (kw/rpm) | 135/2050 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.7 |
| Working form | Efi, 4-stroke, turbocharged, air-to-air cold |
| Ground specific pressure (Kpa) | 47.2 |
| Rotation speed (rpm) | 11.8 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 149 |
| Rod digging force (kN) | 111 |
| Maximum tractive force (kN) | 184 |
| Travel speed (km/h) | 5.4/3.1 |
| Maximum flow of main pump (l/min) | 2*216 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 220 |
| Engine Oil changes (L) | 19.5 |
| Total transport length (mm) | 9625 |
| Total transport width (mm) | 2990 |
| Total transport height (mm) | 3100 |
| Counterweight ground clearance (mm) | 1050 |
| Minimum ground clearance (mm) | 486 |
| Minimum turning radius of front working device (mm) | 3530 |
| Back end turning radius (mm) | 2844 |
| Total track length (mm) | 4255 |
| Track gauge (mm) | 2390 |
| Track plate width (mm) | 600 |
| Maximum digging radius (mm) | 9940 |
| Maximum digging depth (mm) | 6680 |
| Maximum excavation height (mm) | 9620 |
| Maximum unloading height (mm) | 6780 |
| Maximum vertical digging depth (mm) | 5715 |
