Product Description
With a robust 22-ton working weight and a powerful 4HK1 engine, the XCMG XE225DK excavator is site-ready for immediate deployment. Featuring a 1.14 m³ bucket capacity and a maximum digging force of 149 kN, this machine excels in demanding tasks such as digging, grading, and demolition. Its 5680 mm boom and 2910 mm rod ensure an impressive reach, with a maximum digging depth of 6680 mm and a maximum excavation height of 9620 mm. Water-cooled and turbocharged, the 4-stroke engine delivers 140 kW at 2000 rpm, providing the necessary power for efficient operation. Equipped with a 400 L fuel tank and 220 L hydraulic system, the XE225DK is designed for long, uninterrupted work sessions. Located in 福建, this excavator is ready to tackle your most challenging projects.
| Specifications | Value |
|---|---|
| No. | 1020635 |
| Tonnage (tons) | 22 |
| Working weight (kg) | 22100 |
| Bucket capacity (m³) | 1.0-1.2 (1.14) |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2910 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 4HK1 |
| Rated power (kw/rpm) | 140/2000 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 676/1800 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 5.3 |
| Working form | Efi, 4-stroke, turbocharged, air-to-air cold |
| Ground specific pressure (Kpa) | 47.2 |
| Rotation speed (rpm) | 11.8 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 149 |
| Rod digging force (kN) | 111 |
| Maximum tractive force (kN) | 184 |
| Travel speed (km/h) | 5.3/3.0 |
| Fuel Tank (L) | 400 |
| Engine Oil changes (L) | 19.5 |
| Hydraulic System (L) | 220 |
| Total transport length (mm) | 9625 |
| Total transport width (mm) | 2990 |
| Total transport height (mm) | 3100 |
| Counterweight ground clearance (mm) | 1050 |
| Minimum ground clearance (mm) | 486 |
| Minimum turning radius of front working device (mm) | 3530 |
| Back end turning radius (mm) | 2890 |
| Total track length (mm) | 4255 |
| Track gauge (mm) | 2390 |
| Total track width (mm) | 600 |
| Maximum digging radius (mm) | 9940 |
| Maximum digging depth (mm) | 6680 |
| Maximum excavation height (mm) | 9620 |
| Maximum unloading height (mm) | 6780 |
| Maximum vertical digging depth (mm) | 5715 |
