Product Description
Built for endurance, this 2016 XCMG XE230 excavator demonstrates proven reliability through eight years of consistent performance. Operating at 23 tons with a robust ISUZU CC-6BG1TRP engine delivering 125kW of power, this machine has established itself as a dependable workhorse in demanding construction environments.
Key specifications showcase its industrial capabilities:
- Maximum digging reach of 10.27 meters with 6.92-meter depth capacity
- Powerful 163kN bucket digging force for challenging excavation tasks
- Efficient 1m³ bucket capacity optimized for productivity
- Dual variable pump hydraulic system ensuring consistent performance
- 400L fuel tank providing extended operational periods
Currently located in Xinyu, Jiangxi, this excavator represents solid Chinese engineering from Xuzhou manufacturing. With its water-cooled 4-cylinder engine and plunger hydraulic motor configuration, the XE230 continues delivering the durability XCMG built into every component. Proven track record speaks louder than promises—this machine works.
| Specifications | Value |
|---|---|
| No. | 991477 |
| Tonnage (tons) | 23 |
| Working weight (kg) | 23520 |
| Bucket capacity (m³) | 1 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | ISUZU CC-6BG1TRP |
| Rated power (kw/rpm) | 125/2100 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 6.494 |
| Rotation speed (rpm) | 12.1 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 163 |
| Travel speed (km/h) | 3.5/5.5 |
| Rotary hydraulic motor type | Plunger hydraulic motor |
| Type of walking hydraulic motor | Plunger hydraulic motor |
| Main pump type | Variable pump ×2 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 240 |
| Total transport length (mm) | 10,160 |
| Total transport width (mm) | 2,990 |
| Total transport height (mm) | 3,050 |
| Back end turning radius (mm) | 2,940 |
| Total track length (mm) | 4,255 |
| Track gauge (mm) | 2,390 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3,462 |
| Maximum digging radius (mm) | 10,270 |
| Maximum digging depth (mm) | 6,920 |
| Maximum excavation height (mm) | 9,670 |
| Maximum unloading height (mm) | 6,795 |
| Maximum vertical digging depth (mm) | 6,165 |
| Bulldozer lift or depth (mm) | No bulldozer |
| Dodging plate width × height (mm) | No bulldozer |
