Product Description
Maximize your equipment budget with this 2016 XCMG XE245DK excavator, currently located in Luzhou, Sichuan. Delivering robust 24-ton performance at a fraction of new equipment costs, this machine represents exceptional value for contractors seeking proven capability without premium pricing. Powered by a reliable QSB7 engine generating 150kW at 2050rpm, it combines a 6.7L displacement with efficient EFI technology and turbocharged performance for demanding jobsite conditions.
Operational specifications include:
- Working weight: 25,500kg with 0.9-1.4m³ bucket capacity
- Maximum digging reach of 10,240mm and depth of 6,972mm
- Impressive digging forces: 185kN bucket, 129kN rod
- 400L fuel tank and 220L hydraulic reservoir for extended operation
- 35% climbing ability with 11.2rpm rotation speed
Built with traditional power systems and proven Chinese manufacturing, this backhoe-equipped excavator offers dependable productivity for earthmoving, trenching, and general construction applications. Smart buyers recognize that well-maintained used equipment delivers comparable performance to new machines while preserving capital for other business investments. Contact us today to i
| Specifications | Value |
|---|---|
| No. | 1005518 |
| Tonnage (tons) | 24 |
| Working weight (kg) | 25500 |
| Bucket capacity (m³) | 0.9-1.4 |
| Boom length (mm) | 6000 |
| Rod length (mm) | 2964 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | QSB7 |
| Rated power (kw/rpm) | 150/2050 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.7 |
| Working form | Efi, 4-stroke, turbocharged, air-to-air cold |
| Ground specific pressure (Kpa) | 56.7 |
| Rotation speed (rpm) | 11.2 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 185 |
| Rod digging force (kN) | 129 |
| Maximum tractive force (kN) | 199 |
| Travel speed (km/h) | 5.3/3.6 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 220 |
| Engine Oil changes (L) | 19.5 |
| Total transport length (mm) | 10170 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3130 |
| Counterweight ground clearance (mm) | 1062 |
| Minimum ground clearance (mm) | 1062 |
| Minimum turning radius of front working device (mm) | 3510 |
| Back end turning radius (mm) | 2955 |
| Total track length (mm) | 4445 |
| Track gauge (mm) | 2590 |
| Total track width (mm) | 3190 |
| Maximum digging radius (mm) | 10240 |
| Maximum digging depth (mm) | 6972 |
| Maximum excavation height (mm) | 10048 |
| Maximum unloading height (mm) | 7123 |
| Maximum vertical digging depth (mm) | 5567 |
