Product Description
Strengthen your fleet capacity with this 2020 XCMG XE245DK excavator, currently positioned in Guizhou and ready for immediate deployment. Built for contractors managing multiple projects simultaneously, this 24-ton workhorse delivers consistent performance with its 150kW QSB7 engine and proven hydraulic systems. Operating weight of 25,500kg provides stability across varied terrain, while the 6-meter boom and 2,964mm arm configuration offer a maximum digging reach of 10,240mm and depth capability of 6,972mm.
- Bucket capacity: 0.9-1.4m³ for versatile material handling
- Powerful digging forces: 185kN bucket force, 129kN arm force
- Extended runtime: 400L fuel tank minimizes refueling downtime
- Compact transport dimensions: 10,170mm × 3,190mm × 3,130mm
- Reliable 6-cylinder turbocharged engine with air-to-air cooling
- 35% grading ability handles challenging site conditions
Perfect as a backup unit during peak season or as a permanent fleet addition, this machine integrates seamlessly into existing XCMG operations. Standard backhoe configuration and straightforward maintenance requirements ensure your operators can transition quickly with minimal training investment.
| Specifications | Value |
|---|---|
| No. | 1005335 |
| Tonnage (tons) | 24 |
| Working weight (kg) | 25500 |
| Bucket capacity (m³) | 0.9-1.4 |
| Boom length (mm) | 6000 |
| Rod length (mm) | 2964 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | QSB7 |
| Rated power (kw/rpm) | 150/2050 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.7 |
| Working form | Efi, 4-stroke, turbocharged, air-to-air cold |
| Ground specific pressure (Kpa) | 56.7 |
| Rotation speed (rpm) | 11.2 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 185 |
| Rod digging force (kN) | 129 |
| Maximum tractive force (kN) | 199 |
| Travel speed (km/h) | 5.3/3.6 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 220 |
| Engine Oil changes (L) | 19.5 |
| Total transport length (mm) | 10170 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3130 |
| Counterweight ground clearance (mm) | 1062 |
| Minimum ground clearance (mm) | 1062 |
| Minimum turning radius of front working device (mm) | 3510 |
| Back end turning radius (mm) | 2955 |
| Total track length (mm) | 4445 |
| Track gauge (mm) | 2590 |
| Total track width (mm) | 3190 |
| Maximum digging radius (mm) | 10240 |
| Maximum digging depth (mm) | 6972 |
| Maximum excavation height (mm) | 10048 |
| Maximum unloading height (mm) | 7123 |
| Maximum vertical digging depth (mm) | 5567 |
