Product Description
This 2013 XCMG XE265C hydraulic excavator represents a proven workhorse from one of China's leading construction equipment manufacturers. With a decade of operational history, this mid-size crawler excavator offers reliable performance for various earthmoving and excavation applications. The XE265C is designed with a robust undercarriage and efficient hydraulic system, making it suitable for construction sites, mining operations, and infrastructure projects.
Currently located in Sichuan, China, this machine provides an accessible option for buyers seeking dependable used excavation equipment in the region. XCMG's 26-ton class excavators are known for their durability and straightforward maintenance requirements.
- Year of Manufacture: 2013
- Brand: XCMG
- Model: XE265C
- Category: Hydraulic Excavator
- Location: Sichuan Province, China
- Condition: Used
Ideal for contractors and operators requiring cost-effective excavation capacity with established brand support throughout Asia-Pacific markets.
| Specifications | Value |
|---|---|
| No. | 1099758 |
| Tonnage (tons) | 26 |
| Working weight (kg) | 25500 |
| Bucket capacity (m³) | 1.05 ~ 1.25 |
| Boom length (mm) | 6000 |
| Rod length (mm) | 2960 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | ISUZU CC-6BG1TRP-05 |
| Rated power (kw/rpm) | 135.5/2150 |
| Maximum torque (N.m/rpm) | 637 |
| Ground specific pressure (Kpa) | 50.1 |
| Rotation speed (rpm) | 11.3 |
| Climbing ability (%) | 35 or less |
| Bucket digging force (kN) | 161 |
| Rod digging force (kN) | 125 |
| Maximum tractive force (kN) | 194 |
| Travel speed (km/h) | 5.9/4.0 |
| Main overflow set pressure (Mpa) | 34.3/37 |
| Maximum flow of main pump (l/min) | 2 x 256 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 28 |
| Main pump type | 2 plunger pumps |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 240 |
| Engine Oil changes (L) | 25 |
| Total transport length (mm) | 10160 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3100 |
| Minimum turning radius of front working device (mm) | 3850 |
| Total track length (mm) | 4640 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Maximum digging radius (mm) | 10240 |
| Maximum digging depth (mm) | 6895 |
| Maximum excavation height (mm) | 9662 |
| Maximum unloading height (mm) | 6810 |
| Maximum vertical digging depth (mm) | 5480 |
| Maximum excavation radius of stop surface (mm) | 6750 |
