Product Description
Available now from Zhejiang, China — this 2020 XCMG XE270DK 27-ton excavator ships fast, cutting straight through factory lead times so you can put iron to work on your site without delay. Built for heavy-cycle digging, it pairs a Cummins QSB7 engine (150 kW / 825 N·m peak torque) with a 2×259 L/min dual-pump hydraulic system for consistent, high-force output across long shifts.
- Bucket digging force: 185 kN — rod digging force: 129 kN
- Maximum digging depth: 6,925 mm | Maximum digging radius: 10,240 mm
- Maximum unloading height: 7,170 mm
- Operating weight: 26,500 kg | Bucket capacity: 1.1–1.4 m³
- Max tractive force: 220 kN | Travel speed: 6.1 / 3.8 km/h
- 400 L fuel tank for extended run time between fills
- Ground pressure: 52.1 kPa — suitable for soft and mixed terrain
- Transport dimensions: 10,170 × 3,190 × 3,175 mm
Sourced directly from Zhejiang and ready for fast international deployment, this unit skips the queue. Contact Fair Trade Machinery today to confirm availability and arrange shipping to your project site.
| Specifications | Value |
|---|---|
| No. | 1071088 |
| Tonnage (tons) | 27 |
| Working weight (kg) | 26500 |
| Bucket capacity (m³) | 1.1-1.4 |
| Boom length (mm) | 6000 |
| Rod length (mm) | 2964 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | QSB7 |
| Rated power (kw/rpm) | 150/2050 |
| Maximum torque (N.m) | 825/1250 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.7 |
| Working form | Efi, 4-stroke, turbocharged, air-to-air cold |
| Ground specific pressure (Kpa) | 52.1 |
| Rotation speed (rpm) | 11.4 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 185 |
| Rod digging force (kN) | 129 |
| Maximum tractive force (kN) | 220 |
| Travel speed (km/h) | 6.1/3.8 |
| Maximum flow of main pump (l/min) | 2*259 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 220 |
| Engine Oil changes (L) | 19.5 |
| Total transport length (mm) | 10170 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3175 |
| Counterweight ground clearance (mm) | 1090 |
| Minimum ground clearance (mm) | 495 |
| Minimum turning radius of front working device (mm) | 3510 |
| Back end turning radius (mm) | 2955 |
| Total track length (mm) | 4640 |
| Track gauge (mm) | 2590 |
| Total track width (mm) | 600 |
| Maximum digging radius (mm) | 10240 |
| Maximum digging depth (mm) | 6925 |
| Maximum excavation height (mm) | 10095 |
| Maximum unloading height (mm) | 7170 |
| Maximum vertical digging depth (mm) | 5620 |
