Product Description
This 2020 XCMG XE270DK hydraulic excavator offers reliable performance for medium to heavy-duty construction and earthmoving applications. As a well-established model in XCMG's crawler excavator lineup, the XE270DK combines proven engineering with operational efficiency. Currently located in Sichuan, China, this used machine represents a cost-effective solution for contractors and industrial operators seeking dependable excavation equipment.
Key features include:
- Operating weight class approximately 27 tonnes
- Fuel-efficient diesel engine designed for extended work cycles
- Robust undercarriage built for challenging terrain
- Spacious operator cabin with ergonomic controls
- Hydraulic system engineered for responsive digging and lifting
- Low operational hours consistent with 2020 manufacture year
The XE270DK is suitable for excavation, trenching, loading, and general construction tasks. This unit is available for inspection in Sichuan province and ready for immediate deployment to your worksite.
| Specifications | Value |
|---|---|
| No. | 1096381 |
| Tonnage (tons) | 27 |
| Working weight (kg) | 26500 |
| Bucket capacity (m³) | 1.1-1.4 |
| Boom length (mm) | 6000 |
| Rod length (mm) | 2964 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | QSB7 |
| Rated power (kw/rpm) | 150/2050 |
| Maximum torque (N.m) | 825/1250 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.7 |
| Working form | Efi, 4-stroke, turbocharged, air-to-air cold |
| Ground specific pressure (Kpa) | 52.1 |
| Rotation speed (rpm) | 11.4 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 185 |
| Rod digging force (kN) | 129 |
| Maximum tractive force (kN) | 220 |
| Travel speed (km/h) | 6.1/3.8 |
| Maximum flow of main pump (l/min) | 2*259 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 220 |
| Engine Oil changes (L) | 19.5 |
| Total transport length (mm) | 10170 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3175 |
| Counterweight ground clearance (mm) | 1090 |
| Minimum ground clearance (mm) | 495 |
| Minimum turning radius of front working device (mm) | 3510 |
| Back end turning radius (mm) | 2955 |
| Total track length (mm) | 4640 |
| Track gauge (mm) | 2590 |
| Total track width (mm) | 600 |
| Maximum digging radius (mm) | 10240 |
| Maximum digging depth (mm) | 6925 |
| Maximum excavation height (mm) | 10095 |
| Maximum unloading height (mm) | 7170 |
| Maximum vertical digging depth (mm) | 5620 |
