Product Description
Engineered for high-capacity excavation operations, this 33-ton hydraulic excavator delivers industrial-grade performance through proven mechanical design. Powered by a 6-cylinder ISUZU turbocharged engine generating 184kW at 2000rpm with water-to-air intercooling, the XE335C provides consistent power delivery across demanding work cycles. The dual plunger hydraulic system supplies 560 L/min combined flow at 34.3 MPa, enabling a bucket digging force of 263kN and stick force of 225kN—specifications that translate directly to productivity in heavy earthmoving applications.
Technical highlights include:
- Maximum digging reach of 10,720mm with 6,912mm depth capability
- 1.4-1.6m³ bucket capacity matched to 33,800kg operating weight
- 6,400mm boom and 2,670mm stick configuration for optimal breakout geometry
- 630L fuel capacity supporting extended operational periods
- 9.7 rpm swing speed with 35° gradeability for versatile site mobility
Manufactured in Xuzhou with systematic quality controls, this model represents XCMG's commitment to durable construction equipment. Currently located in Guangzhou, Guangdong, the machine offers proven reliability for contractors requiring de
| Specifications | Value |
|---|---|
| No. | 1034102 |
| Tonnage (tons) | 33 |
| Working weight (kg) | 33800 |
| Bucket capacity (m³) | 1.4-1.6 |
| Boom length (mm) | 6400 |
| Rod length (mm) | 2670 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | The ISUZU Isuzu |
| Rated power (kw/rpm) | 184/2000 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 7.79 |
| Working form | Turbocharged/air-to-air cooling |
| Ground specific pressure (Kpa) | 66 |
| Rotation speed (rpm) | 9.7 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 263 |
| Rod digging force (kN) | 225 |
| Travel speed (km/h) | 5.5/3.3 |
| Main overflow set pressure (Mpa) | 34.3/37 |
| Maximum flow of main pump (l/min) | 2*280 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 26.5 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Two plunger pumps |
| Pilot pump flow (L/min) | 3.9 |
| Fuel Tank (L) | 630 |
| Hydraulic Tank (L) | 320 |
| Engine Oil changes (L) | 28 |
| Total transport length (mm) | 11226 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3330 |
| Counterweight ground clearance (mm) | 1170 |
| Minimum ground clearance (mm) | 495 |
| Minimum turning radius of front working device (mm) | 4424 |
| Back end turning radius (mm) | 3450 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3183 |
| Maximum digging radius (mm) | 10720 |
| Maximum digging depth (mm) | 6912 |
| Maximum excavation height (mm) | 10360 |
| Maximum unloading height (mm) | 7134 |
| Maximum vertical digging depth (mm) | 6480 |
