Product Description
Available now from Guangdong, China — this 2022 XCMG XE335C 33-ton hydraulic excavator ships fast. Skip the factory lead times and get proven heavy iron deployed to your site without delay. Stocked and ready, this machine moves when you need it to.
Powered by a 6-cylinder ISUZU turbocharged water-cooled engine rated at 184 kW / 2000 rpm with 7.79L displacement, the XE335C delivers serious digging performance backed by dual 280 L/min plunger pumps and a 34.3 MPa hydraulic system.
- Working Weight: 33,800 kg | Bucket Capacity: 1.4–1.6 m³
- Bucket Digging Force: 263 kN | Rod Digging Force: 225 kN
- Max Digging Depth: 6,912 mm | Max Digging Radius: 10,720 mm
- Max Excavation Height: 10,360 mm | Max Unloading Height: 7,134 mm
- Travel Speed: 5.5 / 3.3 km/h | Climbing Ability: 35°
- Fuel Tank: 630 L | Hydraulic Tank: 320 L
- Transport Dimensions: 11,226 mm (L) × 3,190 mm (W) × 3,330 mm (H)
Sourced directly from Guangdong with export logistics already in motion. Fast deployment, competitive pricing, and zero factory wait — contact Fair Trade Machinery today to secure this unit.
| Specifications | Value |
|---|---|
| No. | 1092124 |
| Tonnage (tons) | 33 |
| Working weight (kg) | 33800 |
| Bucket capacity (m³) | 1.4-1.6 |
| Boom length (mm) | 6400 |
| Rod length (mm) | 2670 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | The ISUZU Isuzu |
| Rated power (kw/rpm) | 184/2000 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 7.79 |
| Working form | Turbocharged/air-to-air cooling |
| Ground specific pressure (Kpa) | 66 |
| Rotation speed (rpm) | 9.7 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 263 |
| Rod digging force (kN) | 225 |
| Travel speed (km/h) | 5.5/3.3 |
| Main overflow set pressure (Mpa) | 34.3/37 |
| Maximum flow of main pump (l/min) | 2*280 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 26.5 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Two plunger pumps |
| Pilot pump flow (L/min) | 3.9 |
| Fuel Tank (L) | 630 |
| Hydraulic Tank (L) | 320 |
| Engine Oil changes (L) | 28 |
| Total transport length (mm) | 11226 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3330 |
| Counterweight ground clearance (mm) | 1170 |
| Minimum ground clearance (mm) | 495 |
| Minimum turning radius of front working device (mm) | 4424 |
| Back end turning radius (mm) | 3450 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3183 |
| Maximum digging radius (mm) | 10720 |
| Maximum digging depth (mm) | 6912 |
| Maximum excavation height (mm) | 10360 |
| Maximum unloading height (mm) | 7134 |
| Maximum vertical digging depth (mm) | 6480 |
