Product Description
Built for demanding construction environments, this 2017 XCMG XE335DK excavator delivers proven performance with 33-ton operating capacity and robust QSL9 engine technology. XCMG's established manufacturing excellence ensures reliable parts availability and strong resale value retention in today's used equipment market.
Key performance specifications include:
- 202kW rated power at 2100 RPM with 8.9L displacement
- Maximum digging reach of 10,680mm and depth capability to 6,735mm
- Bucket capacity range of 1.6-2.0m³ for versatile material handling
- Dual main pump system delivering 2×272 L/min hydraulic flow
- 70% climbing ability with 260kN maximum tractive force
Located in Zhejiang Shaoxing, this machine represents XCMG's commitment to engineering durability and operational efficiency. With comprehensive service network support across China and internationally, parts procurement remains straightforward while maintaining competitive operating costs. XCMG's reputation for manufacturing quality translates directly into sustained equipment value and reduced ownership risk for discerning buyers.
| Specifications | Value |
|---|---|
| No. | 991538 |
| Tonnage (tons) | 33 |
| Working weight (kg) | 33500 |
| Bucket capacity (m³) | 1.6-2.0 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | QSL9 |
| Rated power (kw/rpm) | 202/2100 |
| Displacement (L) | 8.9 |
| Ground specific pressure (Kpa) | 61.4 |
| Rotation speed (rpm) | 10.5 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 206 |
| Rod digging force (kN) | 160 |
| Maximum tractive force (kN) | 260 |
| Travel speed (km/h) | 5.3/3.2 |
| Maximum flow of main pump (l/min) | 2*272 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 30 |
| Fuel Tank (L) | 520 |
| Hydraulic Tank (L) | 270 |
| Engine Oil changes (L) | 30 |
| Total transport length (mm) | 10790 |
| Total transport width (mm) | 3200 |
| Total transport height (mm) | 3640 |
| Counterweight ground clearance (mm) | 1198 |
| Minimum ground clearance (mm) | 538 |
| Minimum turning radius of front working device (mm) | 4125 |
| Back end turning radius (mm) | 3360 |
| Total track length (mm) | 4944 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Maximum digging radius (mm) | 10680 |
| Maximum digging depth (mm) | 6735 |
| Maximum excavation height (mm) | 10265 |
| Maximum unloading height (mm) | 7110 |
| Maximum vertical digging depth (mm) | 5010 |
