Product Description
Built to withstand the demanding conditions of heavy construction, this 2016 XCMG XE370C excavator represents proven engineering excellence from one of China's leading manufacturers. Operating at 37 tons with a robust working weight of 36,600 kg, this machine delivers consistent performance through its reliable ISUZU 6-cylinder engine, generating 184 kW at 2000 rpm with an impressive maximum torque of 872.8 N·m. Currently located in Guizhou, this proven workhorse features a 1.6 m³ backhoe bucket configuration designed for maximum productivity.
Durability defines every aspect of this excavator's design. Key performance specifications include:
- Maximum digging depth of 7,423 mm with 242 kN bucket digging force
- Water-cooled turbocharged engine with 7.79L displacement for sustained power delivery
- Dual plunger hydraulic pumps providing 2×280 l/min flow capacity
- 58% climbing ability and 10.1 rpm rotation speed for versatile operation
- 600L fuel tank and 320L hydraulic tank for extended work cycles
Years of field-proven reliability make this XE370C an intelligent investment for contractors requiring dependable excavation performance without compromise.
| Specifications | Value |
|---|---|
| No. | 1005395 |
| Tonnage (tons) | 37 |
| Working weight (kg) | 36600 |
| Bucket capacity (m³) | 1.6 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | The ISUZU Isuzu |
| Rated power (kw/rpm) | 184/2000 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 7.79 |
| Working form | Direct injection; 4 strokes; Water cooling; Turbocharging; Air to air cold; Maximum torque 872.8/1700N.m |
| Ground specific pressure (Kpa) | 67.8 |
| Rotation speed (rpm) | 10.1 |
| Climbing ability (%) | 58 |
| Bucket digging force (kN) | 242 |
| Rod digging force (kN) | 174 |
| Travel speed (km/h) | 5.4/3.2 |
| Main overflow set pressure (Mpa) | 31.5/34.3 |
| Maximum flow of main pump (l/min) | 2x280 |
| Main pump type | Two plunger pumps |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 600 |
| Hydraulic Tank (L) | 320 |
| Engine Oil changes (L) | 28 |
| Total transport length (mm) | 11105 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3300 |
| Counterweight ground clearance (mm) | 1197 |
| Minimum ground clearance (mm) | 500 |
| Minimum turning radius of front working device (mm) | 4343 |
| Back end turning radius (mm) | 3450 |
| Total track length (mm) | 5070 |
| Track gauge (mm) | 2525 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3190 |
| Maximum digging radius (mm) | 11114 |
| Maximum digging depth (mm) | 7423 |
| Maximum excavation height (mm) | 10445 |
| Maximum unloading height (mm) | 7287 |
| Maximum vertical digging depth (mm) | 6776 |
| Maximum excavation radius of stop surface (mm) | 10907 |
| Maximum effective digging depth (mm) | 7266 |
