Product Description
Engineered for demanding excavation work, this 37-ton crawler excavator delivers exceptional operator control and worksite productivity. Powered by a robust GH-6HK1XKSC-03 engine producing 212 kW at 2000 rpm, it combines 263 kN bucket digging force with precise hydraulic flow management through dual 296 l/min main pumps. Operators benefit from commanding visibility across an 11,114 mm maximum digging radius, while the spacious cabin provides unobstructed sightlines to the 6,400 mm boom and 3,200 mm arm during precision grading or deep trenching operations.
- Operating weight: 36,800 kg with superior 66.7 kPa ground pressure distribution
- Digging depth reaches 7,423 mm; maximum height extends to 10,445 mm
- 9.7 rpm rotation speed ensures smooth, controlled swing movements
- Stable 2,590 mm track gauge with 600 mm-wide plates for consistent footing
- 70% gradeability and 285 kN tractive force for challenging terrain
- Dual-speed travel: 5.4/3.2 km/h for efficient site repositioning
- 660 L fuel capacity supports extended operating shifts
Currently located in Wenzhou, Zhejiang, this machine represents proven Chinese manufacturing with operator-focused ergonomics for
| Specifications | Value |
|---|---|
| No. | 1013918 |
| Tonnage (tons) | 37 |
| Working weight (kg) | 36800 |
| Bucket capacity (m³) | 1.7-1.9 |
| Boom length (mm) | 6400 |
| Rod length (mm) | 3200 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | GH-6HK1XKSC-03 |
| Rated power (kw/rpm) | 212/2000 |
| Maximum torque (N.m) | 1080/1500 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 7.79 |
| Ground specific pressure (Kpa) | 66.7 |
| Rotation speed (rpm) | 9.7 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 263 |
| Rod digging force (kN) | 188 |
| Maximum tractive force (kN) | 285 |
| Travel speed (km/h) | 5.4/3.2 |
| Maximum flow of main pump (l/min) | 2*296 |
| Fuel Tank (L) | 660 |
| Hydraulic Tank (L) | 350 |
| Engine Oil changes (L) | 30 |
| Total transport length (mm) | 11388 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3530 |
| Counterweight ground clearance (mm) | 1197 |
| Minimum ground clearance (mm) | 500 |
| Minimum turning radius of front working device (mm) | 4369 |
| Back end turning radius (mm) | 3700 |
| Total track length (mm) | 5035 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3190 |
| Maximum digging radius (mm) | 11114 |
| Maximum digging depth (mm) | 7423 |
| Maximum excavation height (mm) | 10445 |
| Maximum unloading height (mm) | 7287 |
| Maximum vertical digging depth (mm) | 6776 |
