Product Description
With a working weight of 4050 kg and powered by the reliable Yanmar 4TNV88 engine, this 2019 XCMG XE40 excavator from 广东深圳 offers a smart investment for your construction needs. Delivering 27.1 kW at 2200 rpm, it ensures high performance without the premium price tag of new machinery. Featuring a 0.14 m³ bucket capacity and a boom length of 2795 mm, it is designed for efficiency and durability. The XE40 boasts a maximum digging depth of 3600 mm and a digging force of 23.2 kN, making it ideal for various excavation tasks. Its 4-cylinder water-cooled engine, combined with a robust hydraulic system, provides consistent power and reliability. Choose this used XCMG XE40 for a cost-effective solution that doesn't compromise on quality or performance.
- Working weight: 4050 kg
- Bucket capacity: 0.14 m³
- Boom length: 2795 mm
- Engine: Yanmar 4TNV88, 27.1 kW/2200 rpm
- Maximum digging depth: 3600 mm
- Digging force: 23.2 kN
| Specifications | Value |
|---|---|
| No. | 1002691 |
| Tonnage (tons) | 4 |
| Working weight (kg) | 4050 |
| Bucket capacity (m³) | 0.14 |
| Boom length (mm) | 2795 |
| Rod length (mm) | 1600 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar Yanmar 4TNV88 |
| Rated power (kw/rpm) | 27.1/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 2.19 |
| Ground specific pressure (Kpa) | 23.6 |
| Rotation speed (rpm) | 13.5 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 23.2 |
| Rod digging force (kN) | 19.3 |
| Travel speed (km/h) | 4.2/2.6 |
| Main overflow set pressure (Mpa) | 21 |
| Rotary hydraulic motor type | Plunger hydraulic motor |
| Type of walking hydraulic motor | Plunger hydraulic motor |
| Maximum flow of main pump (l/min) | 1*110+11 |
| Traveling Hydraulic Circuit (Mpa) | 21 |
| Rotary Hydraulic Circuit (Mpa) | 21 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Japan Fujikoshi variable pump ×1+ gear pump ×1 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 65 |
| Engine Oil changes (L) | 7.4 |
| Hydraulic System (L) | 70 |
| Total transport length (mm) | 5455 |
| Total transport width (mm) | 1650 |
| Total transport height (mm) | 2440 |
| Counterweight ground clearance (mm) | 578 |
| Minimum ground clearance (mm) | 350 |
| Minimum turning radius of front working device (mm) | 2385 |
| Back end turning radius (mm) | 1490 |
| Track gauge (mm) | 1335 |
| Track plate width (mm) | 300 |
| Track ground length (mm) | 1721 |
| Maximum digging radius (mm) | 5810 |
| Maximum digging depth (mm) | 3600 |
| Maximum excavation height (mm) | 5320 |
| Maximum unloading height (mm) | 3700 |
| Maximum vertical digging depth (mm) | 2250 |
| Bulldozer lift or depth (mm) | 267/365 |
| Dodging plate width × height (mm) | 1650 x 300 |
