Product Description
Maximize your equipment budget with this 2019 XCMG XE40 compact excavator from Shandong. Delivering professional-grade performance at a fraction of new equipment costs, this 4-ton machine combines proven reliability with exceptional value. Powered by a robust Yanmar 4TNV88 engine producing 27.1kW, it tackles demanding jobsites with 23.2kN bucket digging force and 19.3kN arm digging force. The Japanese Fujikoshi variable pump system ensures precise hydraulic control across all functions.
Key specifications include:
- Maximum digging reach: 5,810mm with 3,600mm depth capability
- Compact footprint: 1,650mm width for confined space access
- 0.14m³ bucket capacity for optimal productivity
- 30° climbing ability and 13.5rpm rotation speed
- Dual travel speeds (4.2/2.6 km/h) for versatile operation
- Water-cooled 4-cylinder engine with 65L fuel capacity
With only four years of service, this Xuzhou-manufactured excavator offers decades of remaining operational life. Smart contractors recognize the financial advantage: acquire proven XCMG engineering quality while preserving capital for additional fleet expansion or project investment. Immediate availability in Shandong.
| Specifications | Value |
|---|---|
| No. | 998939 |
| Tonnage (tons) | 4 |
| Working weight (kg) | 4050 |
| Bucket capacity (m³) | 0.14 |
| Boom length (mm) | 2795 |
| Rod length (mm) | 1600 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar Yanmar 4TNV88 |
| Rated power (kw/rpm) | 27.1/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 2.19 |
| Ground specific pressure (Kpa) | 23.6 |
| Rotation speed (rpm) | 13.5 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 23.2 |
| Rod digging force (kN) | 19.3 |
| Travel speed (km/h) | 4.2/2.6 |
| Main overflow set pressure (Mpa) | 21 |
| Rotary hydraulic motor type | Plunger hydraulic motor |
| Type of walking hydraulic motor | Plunger hydraulic motor |
| Maximum flow of main pump (l/min) | 1*110+11 |
| Traveling Hydraulic Circuit (Mpa) | 21 |
| Rotary Hydraulic Circuit (Mpa) | 21 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Japan Fujikoshi variable pump ×1+ gear pump ×1 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 65 |
| Engine Oil changes (L) | 7.4 |
| Hydraulic System (L) | 70 |
| Total transport length (mm) | 5455 |
| Total transport width (mm) | 1650 |
| Total transport height (mm) | 2440 |
| Counterweight ground clearance (mm) | 578 |
| Minimum ground clearance (mm) | 350 |
| Minimum turning radius of front working device (mm) | 2385 |
| Back end turning radius (mm) | 1490 |
| Track gauge (mm) | 1335 |
| Track plate width (mm) | 300 |
| Track ground length (mm) | 1721 |
| Maximum digging radius (mm) | 5810 |
| Maximum digging depth (mm) | 3600 |
| Maximum excavation height (mm) | 5320 |
| Maximum unloading height (mm) | 3700 |
| Maximum vertical digging depth (mm) | 2250 |
| Bulldozer lift or depth (mm) | 267/365 |
| Dodging plate width × height (mm) | 1650 x 300 |
