Product Description
Built for precision and control, this 2020 XCMG XE40 mini excavator delivers exceptional maneuverability in confined job sites. Operating at 4 tons with a compact 1650mm transport width, it navigates tight spaces while maintaining robust digging performance. The Yanmar 4TNV88 engine generates 27.1kW at 2200rpm, paired with a Japanese Fujikoshi variable pump system that ensures responsive hydraulic flow across all functions.
Operators benefit from excellent visibility and stable handling characteristics. The 13.5rpm rotation speed enables smooth, controlled movements, while the 23.6kPa ground pressure minimizes surface disturbance. Standard features include:
- Maximum digging depth of 3600mm with 5810mm reach
- Powerful bucket digging force of 23.2kN
- Dual-speed travel at 4.2/2.6 km/h for efficient repositioning
- Water-cooled 4-cylinder engine with 65L fuel capacity
- 300mm track plates providing superior stability on varied terrain
- 30° climbing ability for challenging gradients
Currently located in Chongqing, this Chinese-manufactured unit combines reliable Yanmar power with proven XCMG engineering for demanding excavation work.
| Specifications | Value |
|---|---|
| No. | 1017863 |
| Tonnage (tons) | 4 |
| Working weight (kg) | 4050 |
| Bucket capacity (m³) | 0.14 |
| Boom length (mm) | 2795 |
| Rod length (mm) | 1600 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar Yanmar 4TNV88 |
| Rated power (kw/rpm) | 27.1/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 2.19 |
| Ground specific pressure (Kpa) | 23.6 |
| Rotation speed (rpm) | 13.5 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 23.2 |
| Rod digging force (kN) | 19.3 |
| Travel speed (km/h) | 4.2/2.6 |
| Main overflow set pressure (Mpa) | 21 |
| Rotary hydraulic motor type | Plunger hydraulic motor |
| Type of walking hydraulic motor | Plunger hydraulic motor |
| Maximum flow of main pump (l/min) | 1*110+11 |
| Traveling Hydraulic Circuit (Mpa) | 21 |
| Rotary Hydraulic Circuit (Mpa) | 21 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Japan Fujikoshi variable pump ×1+ gear pump ×1 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 65 |
| Engine Oil changes (L) | 7.4 |
| Hydraulic System (L) | 70 |
| Total transport length (mm) | 5455 |
| Total transport width (mm) | 1650 |
| Total transport height (mm) | 2440 |
| Counterweight ground clearance (mm) | 578 |
| Minimum ground clearance (mm) | 350 |
| Minimum turning radius of front working device (mm) | 2385 |
| Back end turning radius (mm) | 1490 |
| Track gauge (mm) | 1335 |
| Track plate width (mm) | 300 |
| Track ground length (mm) | 1721 |
| Maximum digging radius (mm) | 5810 |
| Maximum digging depth (mm) | 3600 |
| Maximum excavation height (mm) | 5320 |
| Maximum unloading height (mm) | 3700 |
| Maximum vertical digging depth (mm) | 2250 |
| Bulldozer lift or depth (mm) | 267/365 |
| Dodging plate width × height (mm) | 1650 x 300 |
