Product Description
Engineered for precision and reliability, this 4-ton compact excavator delivers exceptional performance through advanced hydraulic architecture and proven powertrain technology. At its core, a Yanmar 4TNV88 engine generates 27.1 kW at 2200 rpm, paired with a Japanese Fujikoshi variable pump system providing 110 l/min flow capacity. The hydraulic circuit operates at 21 MPa across main, travel, and rotary functions, ensuring consistent power delivery through plunger-type hydraulic motors.
Performance specifications demonstrate superior capability in confined spaces:
- Maximum digging reach: 5810 mm with 3600 mm depth capacity
- Bucket digging force: 23.2 kN; rod digging force: 19.3 kN
- Compact transport dimensions: 5455 × 1650 × 2440 mm
- 30° climbing ability with 23.6 kPa ground pressure
- 2385 mm minimum turning radius for tight-access operations
Built in Xuzhou with water-cooled efficiency and 70-liter hydraulic capacity, the XE40 combines robust construction with operational versatility. Currently available in Hangzhou, Zhejiang, this 2024 model represents XCMG's commitment to engineering excellence in the compact excavator segment.
| Specifications | Value |
|---|---|
| No. | 995044 |
| Tonnage (tons) | 4 |
| Working weight (kg) | 4050 |
| Bucket capacity (m³) | 0.14 |
| Boom length (mm) | 2795 |
| Rod length (mm) | 1600 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar Yanmar 4TNV88 |
| Rated power (kw/rpm) | 27.1/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 2.19 |
| Ground specific pressure (Kpa) | 23.6 |
| Rotation speed (rpm) | 13.5 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 23.2 |
| Rod digging force (kN) | 19.3 |
| Travel speed (km/h) | 4.2/2.6 |
| Main overflow set pressure (Mpa) | 21 |
| Rotary hydraulic motor type | Plunger hydraulic motor |
| Type of walking hydraulic motor | Plunger hydraulic motor |
| Maximum flow of main pump (l/min) | 1*110+11 |
| Traveling Hydraulic Circuit (Mpa) | 21 |
| Rotary Hydraulic Circuit (Mpa) | 21 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Japan Fujikoshi variable pump ×1+ gear pump ×1 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 65 |
| Engine Oil changes (L) | 7.4 |
| Hydraulic System (L) | 70 |
| Total transport length (mm) | 5455 |
| Total transport width (mm) | 1650 |
| Total transport height (mm) | 2440 |
| Counterweight ground clearance (mm) | 578 |
| Minimum ground clearance (mm) | 350 |
| Minimum turning radius of front working device (mm) | 2385 |
| Back end turning radius (mm) | 1490 |
| Track gauge (mm) | 1335 |
| Track plate width (mm) | 300 |
| Track ground length (mm) | 1721 |
| Maximum digging radius (mm) | 5810 |
| Maximum digging depth (mm) | 3600 |
| Maximum excavation height (mm) | 5320 |
| Maximum unloading height (mm) | 3700 |
| Maximum vertical digging depth (mm) | 2250 |
| Bulldozer lift or depth (mm) | 267/365 |
| Dodging plate width × height (mm) | 1650 x 300 |
