Product Description
Proven in the field since 2015, this XCMG XE500C excavator demonstrates the durability that defines professional-grade machinery. Operating at 50 tons with a robust working weight of 47,300 kg, this workhorse delivers consistent performance through its Cummins QSM11 engine, generating 250 kW at 2100 rpm. Built for demanding applications, it features a maximum digging depth of 7,337 mm and an impressive reach of 11,631 mm, backed by a powerful bucket digging force of 284 kN.
Key specifications include:
- Bucket capacity: 2.1-2.5 m³ backhoe configuration
- Dual main pumps: 2 × 360 L/min hydraulic flow
- 7,060 mm boom and 2,900 mm stick for versatile reach
- Maximum unloading height: 7,409 mm
- 35% climbing ability for challenging terrain
- 725 L fuel capacity for extended operation
Currently located in Baoding, Hebei, this Chinese-manufactured excavator has earned its reputation through years of reliable service. Built to withstand the rigors of heavy construction, mining, and earthmoving projects, it represents proven engineering that continues to perform.
| Specifications | Value |
|---|---|
| No. | 1025375 |
| Tonnage (tons) | 50 |
| Working weight (kg) | 47300 |
| Bucket capacity (m³) | 2.1 ~ 2.5 |
| Boom length (mm) | 7060 |
| Rod length (mm) | 2900 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Cummins QSM11 |
| Rated power (kw/rpm) | 250/2100 |
| Maximum torque (N.m/rpm) | 1674/1400 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 11 |
| Ground specific pressure (Kpa) | 85.9 |
| Rotation speed (rpm) | 9 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 284 |
| Rod digging force (kN) | 236 |
| Maximum tractive force (kN) | 236 |
| Travel speed (km/h) | 5.4/3.2 |
| Maximum flow of main pump (l/min) | 2 x 360 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 28.4 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 725 |
| Hydraulic Tank (L) | 430 |
| Engine Oil changes (L) | 38 |
| Total transport length (mm) | 12032 |
| Total transport width (mm) | 3724 |
| Total transport height (mm) | 4165 |
| Counterweight ground clearance (mm) | 1360 |
| Minimum ground clearance (mm) | 703(without tooth height) |
| Back end turning radius (mm) | 3665 |
| Total track length (mm) | 5220 |
| Track gauge (mm) | 2392/2890 |
| Total track width (mm) | 600 |
| Maximum digging radius (mm) | 11631 |
| Maximum digging depth (mm) | 7337 |
| Maximum excavation height (mm) | 10675 |
| Maximum unloading height (mm) | 7409 |
| Maximum vertical digging depth (mm) | 5225 |
