Product Description
Available now in Hebei Baoding, this 2019 XCMG XE500C 50-ton excavator delivers immediate deployment without factory lead times. Powered by a robust Cummins QSM11 engine producing 250 kW at 2100 rpm, this machine combines proven reliability with commanding performance for large-scale earthmoving operations. Skip months of waiting—secure operational capacity on your timeline.
Engineered for heavy-duty applications, the XE500C features a 2.1–2.5 m³ bucket capacity, 11,631 mm maximum digging radius, and 7,337 mm maximum digging depth. Dual main pumps supply 2 × 360 L/min hydraulic flow, while 284 kN bucket digging force tackles demanding soil conditions. The 7,060 mm boom and 2,900 mm arm configuration optimize reach and cycle times across quarry, infrastructure, and mining sites.
Key Specifications:
- Working weight: 47,300 kg with exceptional 85.9 kPa ground pressure distribution
- Travel speed: 5.4/3.2 km/h for efficient site mobility
- Fuel capacity: 725 L for extended operating shifts
- Transport dimensions: 12,032 × 3,724 × 4,165 mm
- 35% grading ability and 9 rpm rotation speed
Fast deployment to your site starts here. Contact Fair Trade Machi
| Specifications | Value |
|---|---|
| No. | 1022412 |
| Tonnage (tons) | 50 |
| Working weight (kg) | 47300 |
| Bucket capacity (m³) | 2.1 ~ 2.5 |
| Boom length (mm) | 7060 |
| Rod length (mm) | 2900 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Cummins QSM11 |
| Rated power (kw/rpm) | 250/2100 |
| Maximum torque (N.m/rpm) | 1674/1400 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 11 |
| Ground specific pressure (Kpa) | 85.9 |
| Rotation speed (rpm) | 9 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 284 |
| Rod digging force (kN) | 236 |
| Maximum tractive force (kN) | 236 |
| Travel speed (km/h) | 5.4/3.2 |
| Maximum flow of main pump (l/min) | 2 x 360 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 28.4 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 725 |
| Hydraulic Tank (L) | 430 |
| Engine Oil changes (L) | 38 |
| Total transport length (mm) | 12032 |
| Total transport width (mm) | 3724 |
| Total transport height (mm) | 4165 |
| Counterweight ground clearance (mm) | 1360 |
| Minimum ground clearance (mm) | 703(without tooth height) |
| Back end turning radius (mm) | 3665 |
| Total track length (mm) | 5220 |
| Track gauge (mm) | 2392/2890 |
| Total track width (mm) | 600 |
| Maximum digging radius (mm) | 11631 |
| Maximum digging depth (mm) | 7337 |
| Maximum excavation height (mm) | 10675 |
| Maximum unloading height (mm) | 7409 |
| Maximum vertical digging depth (mm) | 5225 |
