Product Description
Engineered for maximum productivity, this 2020 XCMG XE500C delivers 50-ton class performance with precision-calibrated hydraulics and robust mechanical design. Powered by a Cummins QSM11 engine generating 250 kW at 2100 rpm and 1674 N·m of torque, this excavator combines reliable power with efficient fuel management from its 725-liter tank. Dual main pumps supply 2 x 360 l/min flow, driving exceptional bucket digging force of 284 kN and rod force of 236 kN through optimized hydraulic circuits operating at 34.3 MPa.
Working dimensions demonstrate the model's engineering superiority:
- Maximum digging reach: 11,631 mm with 7,337 mm depth capability
- Operating weight: 47,300 kg with balanced 85.9 kPa ground pressure
- Bucket capacity: 2.1–2.5 m³ for versatile material handling
- Boom and arm configuration: 7,060 mm + 2,900 mm for optimal geometry
- 35% gradeability and 5.4 km/h travel speed for challenging terrain
Currently located in Sichuan Dazhou, this Chinese-manufactured machine represents proven XCMG design principles with comprehensive technical documentation available upon request.
| Specifications | Value |
|---|---|
| No. | 1023844 |
| Tonnage (tons) | 50 |
| Working weight (kg) | 47300 |
| Bucket capacity (m³) | 2.1 ~ 2.5 |
| Boom length (mm) | 7060 |
| Rod length (mm) | 2900 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Cummins QSM11 |
| Rated power (kw/rpm) | 250/2100 |
| Maximum torque (N.m/rpm) | 1674/1400 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 11 |
| Ground specific pressure (Kpa) | 85.9 |
| Rotation speed (rpm) | 9 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 284 |
| Rod digging force (kN) | 236 |
| Maximum tractive force (kN) | 236 |
| Travel speed (km/h) | 5.4/3.2 |
| Maximum flow of main pump (l/min) | 2 x 360 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 28.4 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 725 |
| Hydraulic Tank (L) | 430 |
| Engine Oil changes (L) | 38 |
| Total transport length (mm) | 12032 |
| Total transport width (mm) | 3724 |
| Total transport height (mm) | 4165 |
| Counterweight ground clearance (mm) | 1360 |
| Minimum ground clearance (mm) | 703(without tooth height) |
| Back end turning radius (mm) | 3665 |
| Total track length (mm) | 5220 |
| Track gauge (mm) | 2392/2890 |
| Total track width (mm) | 600 |
| Maximum digging radius (mm) | 11631 |
| Maximum digging depth (mm) | 7337 |
| Maximum excavation height (mm) | 10675 |
| Maximum unloading height (mm) | 7409 |
| Maximum vertical digging depth (mm) | 5225 |
