Product Description
Available now in Hebei Baoding, this 2011 XCMG XE50C mini excavator delivers immediate deployment without factory wait times. Powered by a proven 4TNV88-SYY engine generating 27.6kW at 2200rpm, this 5-ton workhorse combines compact dimensions (5475mm transport length, 1800mm width) with robust digging performance—3555mm maximum depth and 5810mm reach radius. Perfect for urban construction, utility work, and confined job sites demanding agility and power.
- Operating Weight: 5,030 kg with 0.18m³ bucket capacity
- Digging Force: 23.2kN bucket force, 19.3kN arm force
- Hydraulics: 110 L/min main pump, 70L hydraulic tank
- Mobility: 4.2 km/h travel speed, 30° climbing ability, 1490mm tail swing radius
- Engine: 4-cylinder, 2.19L displacement, 142 N·m max torque
- Fuel Economy: 65L fuel tank for extended operation
Skip months-long factory lead times. This machine undergoes comprehensive inspection and ships fast from Baoding. Ready for immediate site deployment across Asia, Africa, and beyond. Contact Fair Trade Machinery today for competitive export pricing and logistics solu
| Specifications | Value |
|---|---|
| No. | 1019319 |
| Tonnage (tons) | 5 |
| Working weight (kg) | 5030 |
| Bucket capacity (m³) | 0.18 |
| Boom length (mm) | 2795 |
| Rod length (mm) | 1600 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 4TNV88-SYY |
| Rated power (kw/rpm) | 27.6/2200 |
| Maximum torque (N.m/rpm) | 142/1320 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 2.19 |
| Ground specific pressure (Kpa) | 29.5 |
| Rotation speed (rpm) | 13.5 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 23.2 |
| Rod digging force (kN) | 19.3 |
| Maximum tractive force (kN) | 47.7 |
| Travel speed (km/h) | 4.2/2.6 |
| Maximum flow of main pump (l/min) | 1 x 110 + 11 |
| Traveling Hydraulic Circuit (Mpa) | 21 |
| Rotary Hydraulic Circuit (Mpa) | 16.7 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 65 |
| Hydraulic Tank (L) | 70 |
| Engine Oil changes (L) | 7.4 |
| Total transport length (mm) | 5475 |
| Total transport width (mm) | 1800 |
| Total transport height (mm) | 2540 |
| Counterweight ground clearance (mm) | 675 |
| Minimum ground clearance (mm) | 381 |
| Back end turning radius (mm) | 1490 |
| Track gauge (mm) | 1400 |
| Total track width (mm) | 400 |
| Maximum digging radius (mm) | 5810 |
| Maximum digging depth (mm) | 3555 |
| Maximum excavation height (mm) | 5412 |
| Maximum unloading height (mm) | 3788 |
| Maximum vertical digging depth (mm) | 3115 |
| Bulldozer lift or depth (mm) | 718/560 |
| Dodging plate width × height (mm) | 1800/340 |
