Product Description
This 2018 XCMG XE50C compact excavator offers reliable performance for contractors and operators seeking proven Chinese engineering. With six years of service history, this machine demonstrates XCMG's commitment to durability in the 5-ton class excavator segment.
Currently located in Zhejiang, China, this unit is suited for urban construction, landscaping, and utility work where maneuverability and efficiency are essential. The XE50C features a robust hydraulic system and operator-focused cab design typical of XCMG's compact excavator lineup.
- Year: 2018
- Manufacturer: XCMG
- Model: XE50C
- Category: Compact Excavator
- Location: Zhejiang Province, China
This pre-owned excavator represents an opportunity for businesses requiring dependable earthmoving equipment at a competitive price point. Inspection recommended prior to purchase.
| Specifications | Value |
|---|---|
| No. | 1138402 |
| Tonnage (tons) | 5 |
| Working weight (kg) | 5030 |
| Bucket capacity (m³) | 0.18 |
| Boom length (mm) | 2795 |
| Rod length (mm) | 1600 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 4TNV88-SYY |
| Rated power (kw/rpm) | 27.6/2200 |
| Maximum torque (N.m/rpm) | 142/1320 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 2.19 |
| Ground specific pressure (Kpa) | 29.5 |
| Rotation speed (rpm) | 13.5 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 23.2 |
| Rod digging force (kN) | 19.3 |
| Maximum tractive force (kN) | 47.7 |
| Travel speed (km/h) | 4.2/2.6 |
| Maximum flow of main pump (l/min) | 1 x 110 + 11 |
| Traveling Hydraulic Circuit (Mpa) | 21 |
| Rotary Hydraulic Circuit (Mpa) | 16.7 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 65 |
| Hydraulic Tank (L) | 70 |
| Engine Oil changes (L) | 7.4 |
| Total transport length (mm) | 5475 |
| Total transport width (mm) | 1800 |
| Total transport height (mm) | 2540 |
| Counterweight ground clearance (mm) | 675 |
| Minimum ground clearance (mm) | 381 |
| Back end turning radius (mm) | 1490 |
| Track gauge (mm) | 1400 |
| Total track width (mm) | 400 |
| Maximum digging radius (mm) | 5810 |
| Maximum digging depth (mm) | 3555 |
| Maximum excavation height (mm) | 5412 |
| Maximum unloading height (mm) | 3788 |
| Maximum vertical digging depth (mm) | 3115 |
| Bulldozer lift or depth (mm) | 718/560 |
| Dodging plate width × height (mm) | 1800/340 |
