Product Description
Available now from our Hunan facility, this 2021 XCMG XE50C compact excavator eliminates factory lead times and accelerates your project timeline. Powered by a reliable 4TNV88-SYY engine delivering 27.6 kW at 2200 rpm, this 5-ton machine combines proven performance with immediate deployment capability. Skip months of waiting—secure equipment that's inspection-ready and positioned for fast delivery across China and international markets.
Core Specifications:
- Operating weight: 5,030 kg with 0.18 m³ bucket capacity
- Maximum digging reach: 5,810 mm / depth: 3,555 mm
- Bucket digging force: 23.2 kN; rod force: 19.3 kN
- Compact transport dimensions: 5,475 × 1,800 × 2,540 mm
- Hydraulic system: 110 + 11 L/min main pump flow
- 30° climbing ability with 47.7 kN maximum tractive force
Sourced from Hunan with complete service records, this unit offers the reliability of XCMG engineering without production delays. Arrange inspection and coordinate shipping today—your site work starts when the machine arrives, not when the factory schedule permits.
| Specifications | Value |
|---|---|
| No. | 1026187 |
| Tonnage (tons) | 5 |
| Working weight (kg) | 5030 |
| Bucket capacity (m³) | 0.18 |
| Boom length (mm) | 2795 |
| Rod length (mm) | 1600 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 4TNV88-SYY |
| Rated power (kw/rpm) | 27.6/2200 |
| Maximum torque (N.m/rpm) | 142/1320 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 2.19 |
| Ground specific pressure (Kpa) | 29.5 |
| Rotation speed (rpm) | 13.5 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 23.2 |
| Rod digging force (kN) | 19.3 |
| Maximum tractive force (kN) | 47.7 |
| Travel speed (km/h) | 4.2/2.6 |
| Maximum flow of main pump (l/min) | 1 x 110 + 11 |
| Traveling Hydraulic Circuit (Mpa) | 21 |
| Rotary Hydraulic Circuit (Mpa) | 16.7 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 65 |
| Hydraulic Tank (L) | 70 |
| Engine Oil changes (L) | 7.4 |
| Total transport length (mm) | 5475 |
| Total transport width (mm) | 1800 |
| Total transport height (mm) | 2540 |
| Counterweight ground clearance (mm) | 675 |
| Minimum ground clearance (mm) | 381 |
| Back end turning radius (mm) | 1490 |
| Track gauge (mm) | 1400 |
| Total track width (mm) | 400 |
| Maximum digging radius (mm) | 5810 |
| Maximum digging depth (mm) | 3555 |
| Maximum excavation height (mm) | 5412 |
| Maximum unloading height (mm) | 3788 |
| Maximum vertical digging depth (mm) | 3115 |
| Bulldozer lift or depth (mm) | 718/560 |
| Dodging plate width × height (mm) | 1800/340 |
