Product Description
With a robust 55-ton working weight and a powerful Perkins 2206 III N engine, the XCMG XE550DK is an ideal fleet addition for contractors managing high-demand projects. Located in 河北保定, this 2021 model boasts a rated power of 309.5 kW at 2100 rpm, ensuring reliable performance and efficiency.
- Equipped with a 6550 mm boom and 2550 mm rod, it offers versatile digging capabilities.
- Featuring a maximum torque of 1896 N.m at 1400 rpm, it delivers consistent power for tough jobs.
- Travel speeds of 5.2 km/h and 2.9 km/h ensure maneuverability on various terrains.
- The 725-liter fuel tank and 430-liter hydraulic tank support extended operational hours without frequent refueling.
- Designed with a 13-liter, 6-cylinder engine, it provides a solid foundation for long-term reliability and performance.
Integrate the XCMG XE550DK into your fleet to enhance productivity and meet the demands of your most challenging projects.
| Specifications | Value |
|---|---|
| No. | 1020984 |
| Tonnage (tons) | 55 |
| Working weight (kg) | 51200 |
| Boom length (mm) | 6550 |
| Rod length (mm) | 2550 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Perkins 2206 III N |
| Rated power (kw/rpm) | 309.5/2100 |
| Maximum torque (N.m) | 1896/1400 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 13 |
| Ground specific pressure (Kpa) | 88 |
| Rotation speed (rpm) | 9.2 |
| Bucket digging force (kN) | 330 |
| Rod digging force (kN) | 255 |
| Maximum tractive force (kN) | 370 |
| Travel speed (km/h) | 5.2/2.9 |
| Maximum flow of main pump (l/min) | 2*360 |
| Fuel Tank (L) | 725 |
| Hydraulic Tank (L) | 430 |
| Engine Oil changes (L) | 42 |
| Total transport length (mm) | 11870 |
| Total transport width (mm) | 3572 |
| Total transport height (mm) | 4100 |
| Counterweight ground clearance (mm) | 1353 |
| Minimum ground clearance (mm) | 518 |
| Back end turning radius (mm) | 3800 |
| Total track length (mm) | 5470 |
| Track gauge (mm) | 2740 |
| Track plate width (mm) | 600 |
