Product Description
Built for demanding excavation work, this 2021 XCMG XE550DK delivers 55-ton performance with operator-centered engineering. Powered by a Perkins 2206 III N engine generating 309.5 kW at 2100 rpm, this machine combines robust hydraulic power with refined control systems. Dual main pumps supply 720 l/min total flow, enabling precise simultaneous operations while maintaining responsive bucket and arm movements.
Operators benefit from exceptional visibility across the 3800 mm rear turning radius, supported by strategically positioned counterweights at 1353 mm ground clearance. The spacious cabin provides clear sightlines to the 6550 mm boom and 2550 mm arm during grading and trenching operations. Stability remains consistent thanks to 88 kPa ground pressure distribution across 600 mm track plates, while the 2740 mm track gauge ensures balanced performance on uneven terrain.
- Bucket digging force: 330 kN for challenging soil conditions
- Working weight: 51,200 kg with optimized load distribution
- 9.2 rpm rotation speed for efficient cycle times
- 725 L fuel capacity supports extended shifts
- Currently located in Anhui, China
| Specifications | Value |
|---|---|
| No. | 1026622 |
| Tonnage (tons) | 55 |
| Working weight (kg) | 51200 |
| Boom length (mm) | 6550 |
| Rod length (mm) | 2550 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Perkins 2206 III N |
| Rated power (kw/rpm) | 309.5/2100 |
| Maximum torque (N.m) | 1896/1400 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 13 |
| Ground specific pressure (Kpa) | 88 |
| Rotation speed (rpm) | 9.2 |
| Bucket digging force (kN) | 330 |
| Rod digging force (kN) | 255 |
| Maximum tractive force (kN) | 370 |
| Travel speed (km/h) | 5.2/2.9 |
| Maximum flow of main pump (l/min) | 2*360 |
| Fuel Tank (L) | 725 |
| Hydraulic Tank (L) | 430 |
| Engine Oil changes (L) | 42 |
| Total transport length (mm) | 11870 |
| Total transport width (mm) | 3572 |
| Total transport height (mm) | 4100 |
| Counterweight ground clearance (mm) | 1353 |
| Minimum ground clearance (mm) | 518 |
| Back end turning radius (mm) | 3800 |
| Total track length (mm) | 5470 |
| Track gauge (mm) | 2740 |
| Track plate width (mm) | 600 |
