Product Description
Available now from Zhejiang, China — this 2020 XCMG XE55DA 5-ton mini excavator ships fast, bypassing factory lead times so you can get equipment on-site when your project demands it. Built for precision work in tight spaces, this compact machine delivers serious digging performance with a 48.3 kN bucket digging force and a 3,830 mm maximum digging depth.
Powered by a Kubota V2607 water-cooled diesel engine producing 35 kW at 2,200 rpm, the XE55DA runs on direct injection 4-stroke technology with a 2.615 L displacement. A 150 L/min main pump and dual travel speeds of 4.2/2.2 km/h keep operations efficient across varied ground conditions.
- Working weight: 5,750 kg | Bucket capacity: 0.21 m³
- Max digging radius: 6,130 mm | Max excavation height: 5,630 mm
- Max unloading height: 3,945 mm | Vertical digging depth: 2,680 mm
- Max tractive force: 50.5 kN | Climbing ability: 35%
- Transport dimensions: 5,860 × 1,920 × 2,585 mm
- Fuel tank: 110 L | Hydraulic tank: 77 L
- Ground pressure: 31 kPa | Track width: 400 mm
Ready to load and dispatch from Zhejiang — skip the wait and deploy directly to your worksite.
| Specifications | Value |
|---|---|
| No. | 1076310 |
| Tonnage (tons) | 5 |
| Working weight (kg) | 5750 |
| Bucket capacity (m³) | 0.21 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | V2607 |
| Rated power (kw/rpm) | 35/2200 |
| Cooling mode | water-cooling |
| Displacement (L) | 2.615 |
| Working form | Direct injection, 4 strokes |
| Ground specific pressure (Kpa) | 31 |
| Rotation speed (rpm) | 10 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 48.3 |
| Rod digging force (kN) | 32.5 |
| Maximum tractive force (kN) | 50.5 |
| Travel speed (km/h) | 4.2/2.2 |
| Maximum flow of main pump (l/min) | 150 |
| Traveling Hydraulic Circuit (Mpa) | 24.5 |
| Rotary Hydraulic Circuit (Mpa) | 24 |
| Pilot Oil Circuit (MPa) | 3.5 |
| Fuel Tank (L) | 110 |
| Hydraulic Tank (L) | 77 |
| Engine Oil changes (L) | 10 |
| Total transport length (mm) | 5860 |
| Total transport width (mm) | 1920 |
| Total transport height (mm) | 2585 |
| Counterweight ground clearance (mm) | 700 |
| Minimum ground clearance (mm) | 385 |
| Minimum turning radius of front working device (mm) | 2460 |
| Back end turning radius (mm) | 1670 |
| Track gauge (mm) | 1500 |
| Track plate width (mm) | 400 |
| Center distance of support wheel (mm) | 1990 |
| Maximum digging radius (mm) | 6130 |
| Maximum digging depth (mm) | 3830 |
| Maximum excavation height (mm) | 5630 |
| Maximum unloading height (mm) | 3945 |
| Maximum vertical digging depth (mm) | 2680 |
