Product Description
Available now from our Hunan facility, this 2021 XCMG XE55DA mini excavator eliminates factory lead times and accelerates project timelines. Powered by a robust Yanmar V2607 engine delivering 35kW at 2200 rpm, this 5-ton compact workhorse combines proven water-cooled reliability with immediate availability for fast deployment to your site.
Engineered for versatility in confined spaces, the XE55DA offers a maximum digging depth of 3,830mm and a reach of 6,130mm. Hydraulic performance delivers 48.3kN bucket digging force and 32.5kN arm force, supported by a 150 L/min main pump flow. Compact transport dimensions of 5,860mm × 1,920mm × 2,585mm enable efficient logistics across regions.
Key Performance Specifications:
- Operating weight: 5,750kg with 0.21m³ bucket capacity
- Yanmar V2607 diesel engine: 2.615L displacement, direct injection
- Travel speed: 4.2 km/h high / 2.2 km/h low range
- Climbing capability: 35% grade performance
- Fuel capacity: 110L for extended operation
- Ready for immediate shipment from Hunan, China
Skip the wait. Secure reliable Chinese-manufactured equipment with proven XCMG engineering, ready for immediate delivery.
| Specifications | Value |
|---|---|
| No. | 1023748 |
| Tonnage (tons) | 5 |
| Working weight (kg) | 5750 |
| Bucket capacity (m³) | 0.21 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | V2607 |
| Rated power (kw/rpm) | 35/2200 |
| Cooling mode | water-cooling |
| Displacement (L) | 2.615 |
| Working form | Direct injection, 4 strokes |
| Ground specific pressure (Kpa) | 31 |
| Rotation speed (rpm) | 10 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 48.3 |
| Rod digging force (kN) | 32.5 |
| Maximum tractive force (kN) | 50.5 |
| Travel speed (km/h) | 4.2/2.2 |
| Maximum flow of main pump (l/min) | 150 |
| Traveling Hydraulic Circuit (Mpa) | 24.5 |
| Rotary Hydraulic Circuit (Mpa) | 24 |
| Pilot Oil Circuit (MPa) | 3.5 |
| Fuel Tank (L) | 110 |
| Hydraulic Tank (L) | 77 |
| Engine Oil changes (L) | 10 |
| Total transport length (mm) | 5860 |
| Total transport width (mm) | 1920 |
| Total transport height (mm) | 2585 |
| Counterweight ground clearance (mm) | 700 |
| Minimum ground clearance (mm) | 385 |
| Minimum turning radius of front working device (mm) | 2460 |
| Back end turning radius (mm) | 1670 |
| Track gauge (mm) | 1500 |
| Track plate width (mm) | 400 |
| Center distance of support wheel (mm) | 1990 |
| Maximum digging radius (mm) | 6130 |
| Maximum digging depth (mm) | 3830 |
| Maximum excavation height (mm) | 5630 |
| Maximum unloading height (mm) | 3945 |
| Maximum vertical digging depth (mm) | 2680 |
