Product Description
With a working weight of 5960 kg and a bucket capacity ranging from 0.09 to 0.23 m³, the 2013 XCMG XE60 excavator is ready for immediate deployment from 江苏. Powered by a Yanmar 4TNV94L engine, this 6-ton machine delivers 39.8 kW at 2200 rpm, ensuring reliable performance on any job site. Featuring a maximum digging depth of 3830 mm and a digging force of 42.5 kN, it excels in various excavation tasks. Skip the factory lead times and get your project moving with fast delivery to your location. The XE60 is equipped with a Rexroth main pump and a robust hydraulic system, providing efficient and powerful operation. Available now, this excavator is ideal for those needing quick and effective machinery solutions.
- Working weight: 5960 kg
- Bucket capacity: 0.09-0.23 m³
- Engine: Yanmar 4TNV94L, 39.8 kW/2200 rpm
- Maximum digging depth: 3830 mm
- Fast deployment from 江苏
| Specifications | Value |
|---|---|
| No. | 1004004 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5960 |
| Bucket capacity (m³) | 0.09-0.23 |
| Boom length (mm) | 3000 |
| Rod length (mm) | 1600 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar 4TNV94L |
| Rated power (kw/rpm) | 39.8/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.054 |
| Ground specific pressure (Kpa) | 32.1 |
| Rotation speed (rpm) | 9.5 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 42.5 |
| Rod digging force (kN) | 28.5 |
| Travel speed (km/h) | 4.2/2.2 |
| Main overflow set pressure (Mpa) | 22 |
| Maximum flow of main pump (l/min) | 2*60.5+40.3+9.9 |
| Traveling Hydraulic Circuit (Mpa) | 22 |
| Rotary Hydraulic Circuit (Mpa) | 23 |
| Hydraulic crushing pipeline is standard | is |
| Main pump type | Rexroth |
| Pilot Oil Circuit (MPa) | 2.9 |
| Fuel Tank (L) | 110 |
| Hydraulic Tank (L) | 85 |
| Engine Oil changes (L) | 5.3 |
| Total transport length (mm) | 5850 |
| Total transport width (mm) | 1880/1920 |
| Total transport height (mm) | 2585 |
| Counterweight ground clearance (mm) | 694 |
| Minimum ground clearance (mm) | 369 |
| Minimum turning radius of front working device (mm) | 2450 |
| Back end turning radius (mm) | 1650 |
| Track gauge (mm) | 1480/1500 |
| Track plate width (mm) | 400 |
| Track ground length (mm) | 1985/1990 |
| Maximum digging radius (mm) | 6130 |
| Maximum digging depth (mm) | 3830 |
| Maximum excavation height (mm) | 5630 |
| Maximum unloading height (mm) | 3945 |
| Maximum vertical digging depth (mm) | 2680 |
| Dodging plate width × height (mm) | 1880*365/1920*340 |
