Product Description
Built in 2016, this XCMG XE60 mini excavator delivers proven performance backed by one of China's most established heavy equipment manufacturers. Operating at 6 tons with a Yanmar 4TNV94L engine producing 39.8kW, this compact workhorse combines reliable Japanese power with XCMG's robust hydraulic systems. The Rexroth main pump drives dual 60.5 l/min circuits plus auxiliary flows, while 42.5kN bucket digging force and 3,830mm maximum depth handle demanding excavation tasks. Standard hydraulic crushing pipeline and 6,130mm working radius provide jobsite versatility rarely found in this weight class.
XCMG ownership means access to extensive parts networks across Asia, Europe, and beyond—critical for maintaining uptime on used equipment. With total transport dimensions of 5,850mm length and competitive fuel economy from the 110L tank, this Baoding-based unit represents smart economics for contractors seeking dependable mini excavator capacity without premium pricing. Track width options (1,880/1,920mm) and 35° climbing ability ensure adaptability across varied terrain conditions.
| Specifications | Value |
|---|---|
| No. | 1017289 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5960 |
| Bucket capacity (m³) | 0.09-0.23 |
| Boom length (mm) | 3000 |
| Rod length (mm) | 1600 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar 4TNV94L |
| Rated power (kw/rpm) | 39.8/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.054 |
| Ground specific pressure (Kpa) | 32.1 |
| Rotation speed (rpm) | 9.5 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 42.5 |
| Rod digging force (kN) | 28.5 |
| Travel speed (km/h) | 4.2/2.2 |
| Main overflow set pressure (Mpa) | 22 |
| Maximum flow of main pump (l/min) | 2*60.5+40.3+9.9 |
| Traveling Hydraulic Circuit (Mpa) | 22 |
| Rotary Hydraulic Circuit (Mpa) | 23 |
| Hydraulic crushing pipeline is standard | is |
| Main pump type | Rexroth |
| Pilot Oil Circuit (MPa) | 2.9 |
| Fuel Tank (L) | 110 |
| Hydraulic Tank (L) | 85 |
| Engine Oil changes (L) | 5.3 |
| Total transport length (mm) | 5850 |
| Total transport width (mm) | 1880/1920 |
| Total transport height (mm) | 2585 |
| Counterweight ground clearance (mm) | 694 |
| Minimum ground clearance (mm) | 369 |
| Minimum turning radius of front working device (mm) | 2450 |
| Back end turning radius (mm) | 1650 |
| Track gauge (mm) | 1480/1500 |
| Track plate width (mm) | 400 |
| Track ground length (mm) | 1985/1990 |
| Maximum digging radius (mm) | 6130 |
| Maximum digging depth (mm) | 3830 |
| Maximum excavation height (mm) | 5630 |
| Maximum unloading height (mm) | 3945 |
| Maximum vertical digging depth (mm) | 2680 |
| Dodging plate width × height (mm) | 1880*365/1920*340 |
