Product Description
Engineered with precision hydraulics and proven Yanmar power, this 2016 XCMG XE60 delivers 6-ton performance for demanding excavation work. Powered by a Yanmar 4TNV94L engine producing 39.8 kW at 2200 rpm with water-cooling efficiency, this compact excavator combines reliable Japanese engine technology with XCMG's robust Chinese manufacturing standards. The dual Rexroth main pump system flows at 2×60.5+40.3+9.9 L/min, operating at 22 MPa main pressure to generate impressive bucket digging force of 42.5 kN and rod force of 28.5 kN.
Built in Xuzhou with a working weight of 5,960 kg, the XE60 achieves maximum digging depth of 3,830 mm and reach of 6,130 mm through its 3,000 mm boom and 1,600 mm arm configuration. Ground pressure remains low at 32.1 kPa across 400 mm track plates, while maintaining 35° climbing capability and 9.5 rpm rotation speed. Standard hydraulic crushing pipeline, 110L fuel capacity, and 85L hydraulic tank ensure extended operational intervals. Currently located in Jinhua, Zhejiang, this machine represents proven compact excavator engineering for contractors requiring dependable backhoe performance in confined jobsites.
| Specifications | Value |
|---|---|
| No. | 1029819 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5960 |
| Bucket capacity (m³) | 0.09-0.23 |
| Boom length (mm) | 3000 |
| Rod length (mm) | 1600 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar 4TNV94L |
| Rated power (kw/rpm) | 39.8/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.054 |
| Ground specific pressure (Kpa) | 32.1 |
| Rotation speed (rpm) | 9.5 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 42.5 |
| Rod digging force (kN) | 28.5 |
| Travel speed (km/h) | 4.2/2.2 |
| Main overflow set pressure (Mpa) | 22 |
| Maximum flow of main pump (l/min) | 2*60.5+40.3+9.9 |
| Traveling Hydraulic Circuit (Mpa) | 22 |
| Rotary Hydraulic Circuit (Mpa) | 23 |
| Hydraulic crushing pipeline is standard | is |
| Main pump type | Rexroth |
| Pilot Oil Circuit (MPa) | 2.9 |
| Fuel Tank (L) | 110 |
| Hydraulic Tank (L) | 85 |
| Engine Oil changes (L) | 5.3 |
| Total transport length (mm) | 5850 |
| Total transport width (mm) | 1880/1920 |
| Total transport height (mm) | 2585 |
| Counterweight ground clearance (mm) | 694 |
| Minimum ground clearance (mm) | 369 |
| Minimum turning radius of front working device (mm) | 2450 |
| Back end turning radius (mm) | 1650 |
| Track gauge (mm) | 1480/1500 |
| Track plate width (mm) | 400 |
| Track ground length (mm) | 1985/1990 |
| Maximum digging radius (mm) | 6130 |
| Maximum digging depth (mm) | 3830 |
| Maximum excavation height (mm) | 5630 |
| Maximum unloading height (mm) | 3945 |
| Maximum vertical digging depth (mm) | 2680 |
| Dodging plate width × height (mm) | 1880*365/1920*340 |
