Product Description
Proven performance meets compact efficiency in this 2017 XCMG XE60 mini excavator, currently located in Baoding, Hebei. With over six years of operational history, this 6-ton workhorse demonstrates XCMG's commitment to durable construction and reliable engineering. Powered by a robust Yanmar 4TNV94L engine delivering 39.8kW at 2200rpm, this machine combines Japanese engine reliability with Chinese manufacturing value.
Built for demanding jobsites, the XE60 features premium Rexroth hydraulic pumps and an advanced dual-circuit system providing exceptional digging force—42.5kN bucket force and 28.5kN arm force. Maximum digging depth reaches 3,830mm with a working radius of 6,130mm, making it ideal for utility work, landscaping, and confined construction sites. The water-cooled 4-cylinder engine ensures consistent performance across varied conditions.
Key Specifications:
- Operating Weight: 5,960kg with 0.09-0.23m³ bucket capacity
- Compact Transport Dimensions: 5,850mm × 1,920mm × 2,585mm
- Standard Hydraulic Breaker Circuit for versatile attachments
- 35° Climbing Ability with 32.1kPa ground pressure
- Dual-speed travel: 4.2/2.2 km/h for efficient repositioning
| Specifications | Value |
|---|---|
| No. | 1013763 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5960 |
| Bucket capacity (m³) | 0.09-0.23 |
| Boom length (mm) | 3000 |
| Rod length (mm) | 1600 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar 4TNV94L |
| Rated power (kw/rpm) | 39.8/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.054 |
| Ground specific pressure (Kpa) | 32.1 |
| Rotation speed (rpm) | 9.5 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 42.5 |
| Rod digging force (kN) | 28.5 |
| Travel speed (km/h) | 4.2/2.2 |
| Main overflow set pressure (Mpa) | 22 |
| Maximum flow of main pump (l/min) | 2*60.5+40.3+9.9 |
| Traveling Hydraulic Circuit (Mpa) | 22 |
| Rotary Hydraulic Circuit (Mpa) | 23 |
| Hydraulic crushing pipeline is standard | is |
| Main pump type | Rexroth |
| Pilot Oil Circuit (MPa) | 2.9 |
| Fuel Tank (L) | 110 |
| Hydraulic Tank (L) | 85 |
| Engine Oil changes (L) | 5.3 |
| Total transport length (mm) | 5850 |
| Total transport width (mm) | 1880/1920 |
| Total transport height (mm) | 2585 |
| Counterweight ground clearance (mm) | 694 |
| Minimum ground clearance (mm) | 369 |
| Minimum turning radius of front working device (mm) | 2450 |
| Back end turning radius (mm) | 1650 |
| Track gauge (mm) | 1480/1500 |
| Track plate width (mm) | 400 |
| Track ground length (mm) | 1985/1990 |
| Maximum digging radius (mm) | 6130 |
| Maximum digging depth (mm) | 3830 |
| Maximum excavation height (mm) | 5630 |
| Maximum unloading height (mm) | 3945 |
| Maximum vertical digging depth (mm) | 2680 |
| Dodging plate width × height (mm) | 1880*365/1920*340 |
