Product Description
Proven in demanding jobsites across global markets, this 2018 XCMG XE60 mini excavator delivers dependable 6-ton performance backed by one of China's most established heavy equipment manufacturers. Powered by the reliable Yanmar 4TNV94L engine producing 39.8kW at 2200rpm, this compact workhorse combines water-cooled efficiency with Rexroth hydraulic systems for consistent power delivery across all operating conditions.
XCMG's extensive dealer network ensures parts availability remains strong even in secondary markets, protecting your investment with accessible service support and competitive component pricing. Currently located in Baoding, Hebei, this unit features:
- Maximum digging reach of 6,130mm with 3,830mm depth capability
- Bucket capacity ranging 0.09-0.23m³ for versatile applications
- Bucket digging force of 42.5kN and rod force of 28.5kN
- Compact transport dimensions (5,850×1,920×2,585mm) for easy mobilization
- Standard hydraulic crushing pipeline for attachment flexibility
- 35° climbing ability with 32.1kPa ground pressure
With XCMG's established reputation for strong resale value and robust construction, this XE60 represents a calculated investmen
| Specifications | Value |
|---|---|
| No. | 1017215 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5960 |
| Bucket capacity (m³) | 0.09-0.23 |
| Boom length (mm) | 3000 |
| Rod length (mm) | 1600 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar 4TNV94L |
| Rated power (kw/rpm) | 39.8/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.054 |
| Ground specific pressure (Kpa) | 32.1 |
| Rotation speed (rpm) | 9.5 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 42.5 |
| Rod digging force (kN) | 28.5 |
| Travel speed (km/h) | 4.2/2.2 |
| Main overflow set pressure (Mpa) | 22 |
| Maximum flow of main pump (l/min) | 2*60.5+40.3+9.9 |
| Traveling Hydraulic Circuit (Mpa) | 22 |
| Rotary Hydraulic Circuit (Mpa) | 23 |
| Hydraulic crushing pipeline is standard | is |
| Main pump type | Rexroth |
| Pilot Oil Circuit (MPa) | 2.9 |
| Fuel Tank (L) | 110 |
| Hydraulic Tank (L) | 85 |
| Engine Oil changes (L) | 5.3 |
| Total transport length (mm) | 5850 |
| Total transport width (mm) | 1880/1920 |
| Total transport height (mm) | 2585 |
| Counterweight ground clearance (mm) | 694 |
| Minimum ground clearance (mm) | 369 |
| Minimum turning radius of front working device (mm) | 2450 |
| Back end turning radius (mm) | 1650 |
| Track gauge (mm) | 1480/1500 |
| Track plate width (mm) | 400 |
| Track ground length (mm) | 1985/1990 |
| Maximum digging radius (mm) | 6130 |
| Maximum digging depth (mm) | 3830 |
| Maximum excavation height (mm) | 5630 |
| Maximum unloading height (mm) | 3945 |
| Maximum vertical digging depth (mm) | 2680 |
| Dodging plate width × height (mm) | 1880*365/1920*340 |
