2018 XCMG XE60

1/6
Buy XCMG XE60 Used Loader / 1
Buy XCMG XE60 Used Loader / 2
Buy XCMG XE60 Used Loader / 3
Buy XCMG XE60 Used Loader / 4
Buy XCMG XE60 Used Loader / 5
Buy XCMG XE60 Used Loader / 6

Product Description

Available now from Henan, China: a 2018 XCMG XE60 compact excavator with proven field performance. This 6-ton class machine represents XCMG's reliable engineering in the mini excavator segment, designed for versatility across construction, landscaping, and urban infrastructure projects.

This working unit has demonstrated strong operational performance in real-world applications. The XE60 combines compact dimensions with efficient digging capabilities, making it suitable for confined jobsites and utility work where maneuverability is essential.

  • Manufacturing Year: 2018
  • Model: XCMG XE60
  • Category: 6-ton Compact Excavator
  • Current Location: Henan Province, China
  • Condition: Used, field-ready
  • Operational Status: Confirmed working condition

This machine is available for immediate inspection and deployment. Contact our sales team for detailed specifications, current photos, and export arrangements to your destination.

SpecificationsValue
No.1094897
Tonnage (tons)6
Working weight (kg)5960
Bucket capacity (m³)0.09-0.23
Boom length (mm)3000
Rod length (mm)1600
Country of originXuzhou
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeYanmar 4TNV94L
Rated power (kw/rpm)39.8/2200
Cooling modewater-cooling
Number of cylinders (PCS)4
Displacement (L)3.054
Ground specific pressure (Kpa)32.1
Rotation speed (rpm)9.5
Climbing ability (%)35 °
Bucket digging force (kN)42.5
Rod digging force (kN)28.5
Travel speed (km/h)4.2/2.2
Main overflow set pressure (Mpa)22
Maximum flow of main pump (l/min)2*60.5+40.3+9.9
Traveling Hydraulic Circuit (Mpa)22
Rotary Hydraulic Circuit (Mpa)23
Hydraulic crushing pipeline is standardis
Main pump typeRexroth
Pilot Oil Circuit (MPa)2.9
Fuel Tank (L)110
Hydraulic Tank (L)85
Engine Oil changes (L)5.3
Total transport length (mm)5850
Total transport width (mm)1880/1920
Total transport height (mm)2585
Counterweight ground clearance (mm)694
Minimum ground clearance (mm)369
Minimum turning radius of front working device (mm)2450
Back end turning radius (mm)1650
Track gauge (mm)1480/1500
Track plate width (mm)400
Track ground length (mm)1985/1990
Maximum digging radius (mm)6130
Maximum digging depth (mm)3830
Maximum excavation height (mm)5630
Maximum unloading height (mm)3945
Maximum vertical digging depth (mm)2680
Dodging plate width × height (mm)1880*365/1920*340
see more

Overview

No.1094897

Brand Name:

XCMG

Model Number:

XE60

Year:

2018

Location:

Henan China

Pub Date
