Product Description
Built for reliability and proven in demanding conditions, this 2021 XCMG XE60 mini excavator delivers consistent performance across construction and utility projects. With a 5,960 kg working weight and 6-ton capacity, this compact workhorse combines maneuverability with serious digging power. Powered by a robust Yanmar 4TNV94L engine producing 39.8 kW, it tackles challenging terrain with a 35° climbing ability and maintains steady operation through water-cooled efficiency.
Engineered with Rexroth main pumps and hydraulic systems operating at 22 MPa, this machine provides reliable force delivery—42.5 kN bucket digging force and 28.5 kN rod digging force. Maximum digging depth reaches 3,830 mm with a 6,130 mm working radius, offering versatility for trenching, foundation work, and material handling. Standard hydraulic crushing pipeline expands operational capabilities beyond standard excavation.
- Proven Yanmar 4-cylinder diesel engine with 3.054L displacement
- Compact dimensions: 5,850 mm length, 1,880 mm width for tight access
- Dual-speed travel: 4.2/2.2 km/h for efficient site mobility
- 110L fuel capacity for extended operation cycles
- Currently located in Sichuan, China—ready for
| Specifications | Value |
|---|---|
| No. | 1004924 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5960 |
| Bucket capacity (m³) | 0.09-0.23 |
| Boom length (mm) | 3000 |
| Rod length (mm) | 1600 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar 4TNV94L |
| Rated power (kw/rpm) | 39.8/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.054 |
| Ground specific pressure (Kpa) | 32.1 |
| Rotation speed (rpm) | 9.5 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 42.5 |
| Rod digging force (kN) | 28.5 |
| Travel speed (km/h) | 4.2/2.2 |
| Main overflow set pressure (Mpa) | 22 |
| Maximum flow of main pump (l/min) | 2*60.5+40.3+9.9 |
| Traveling Hydraulic Circuit (Mpa) | 22 |
| Rotary Hydraulic Circuit (Mpa) | 23 |
| Hydraulic crushing pipeline is standard | is |
| Main pump type | Rexroth |
| Pilot Oil Circuit (MPa) | 2.9 |
| Fuel Tank (L) | 110 |
| Hydraulic Tank (L) | 85 |
| Engine Oil changes (L) | 5.3 |
| Total transport length (mm) | 5850 |
| Total transport width (mm) | 1880/1920 |
| Total transport height (mm) | 2585 |
| Counterweight ground clearance (mm) | 694 |
| Minimum ground clearance (mm) | 369 |
| Minimum turning radius of front working device (mm) | 2450 |
| Back end turning radius (mm) | 1650 |
| Track gauge (mm) | 1480/1500 |
| Track plate width (mm) | 400 |
| Track ground length (mm) | 1985/1990 |
| Maximum digging radius (mm) | 6130 |
| Maximum digging depth (mm) | 3830 |
| Maximum excavation height (mm) | 5630 |
| Maximum unloading height (mm) | 3945 |
| Maximum vertical digging depth (mm) | 2680 |
| Dodging plate width × height (mm) | 1880*365/1920*340 |
