Product Description
Built for precision work in confined spaces, this 2021 XCMG XE60 mini excavator delivers 6-ton performance with exceptional operator control. Powered by a reliable Yanmar 4TNV94L engine producing 39.8 kW at 2200 rpm, this machine combines responsive hydraulics with stable ground handling. The water-cooled 4-cylinder engine ensures consistent performance during extended shifts, while the Rexroth main pump system provides smooth, controllable operation across all functions.
Operators benefit from superior visibility and maneuverability in tight job sites. With a compact transport width of just 1880 mm and a minimal turning radius of 2450 mm at the front, navigation around obstacles becomes straightforward. The low ground specific pressure of 32.1 kPa minimizes ground disturbance while maintaining stability on soft terrain. Hydraulic performance is substantial—42.5 kN bucket digging force and 28.5 kN rod digging force handle tough excavation tasks efficiently.
Currently located in Shenzhen, Guangdong, this versatile excavator features:
- Maximum digging depth: 3830 mm, reach: 6130 mm
- Standard hydraulic crushing pipeline for attachment flexibility
- 35° climbing ability for challenging grades
| Specifications | Value |
|---|---|
| No. | 1019794 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5960 |
| Bucket capacity (m³) | 0.09-0.23 |
| Boom length (mm) | 3000 |
| Rod length (mm) | 1600 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar 4TNV94L |
| Rated power (kw/rpm) | 39.8/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.054 |
| Ground specific pressure (Kpa) | 32.1 |
| Rotation speed (rpm) | 9.5 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 42.5 |
| Rod digging force (kN) | 28.5 |
| Travel speed (km/h) | 4.2/2.2 |
| Main overflow set pressure (Mpa) | 22 |
| Maximum flow of main pump (l/min) | 2*60.5+40.3+9.9 |
| Traveling Hydraulic Circuit (Mpa) | 22 |
| Rotary Hydraulic Circuit (Mpa) | 23 |
| Hydraulic crushing pipeline is standard | is |
| Main pump type | Rexroth |
| Pilot Oil Circuit (MPa) | 2.9 |
| Fuel Tank (L) | 110 |
| Hydraulic Tank (L) | 85 |
| Engine Oil changes (L) | 5.3 |
| Total transport length (mm) | 5850 |
| Total transport width (mm) | 1880/1920 |
| Total transport height (mm) | 2585 |
| Counterweight ground clearance (mm) | 694 |
| Minimum ground clearance (mm) | 369 |
| Minimum turning radius of front working device (mm) | 2450 |
| Back end turning radius (mm) | 1650 |
| Track gauge (mm) | 1480/1500 |
| Track plate width (mm) | 400 |
| Track ground length (mm) | 1985/1990 |
| Maximum digging radius (mm) | 6130 |
| Maximum digging depth (mm) | 3830 |
| Maximum excavation height (mm) | 5630 |
| Maximum unloading height (mm) | 3945 |
| Maximum vertical digging depth (mm) | 2680 |
| Dodging plate width × height (mm) | 1880*365/1920*340 |
