Product Description
Engineered for precision work in confined spaces, this 6-ton excavator delivers exceptional operator control and jobsite versatility. Powered by a reliable Yanmar 4TNV94L engine producing 39.8 kW at 2200 rpm, the XE60 combines responsive hydraulics with stable performance across demanding terrain. The Rexroth main pump system provides consistent flow rates of 2×60.5+40.3+9.9 l/min, ensuring smooth simultaneous operations.
Operator-focused design prioritizes comfort and productivity during extended shifts. The cabin offers commanding visibility across the 6130mm maximum digging radius, while intuitive controls manage the 42.5 kN bucket digging force with precision. Compact dimensions—5850mm total length and 1880mm width—enable maneuverability in restricted areas without sacrificing stability, supported by 32.1 Kpa ground pressure distribution.
- Maximum digging depth: 3830mm with 3945mm unloading height
- 9.5 rpm rotation speed for efficient positioning
- 35° climbing capability on challenging grades
- Water-cooled 4-cylinder engine with 3.054L displacement
- Standard hydraulic crushing pipeline for attachment versatility
- Dual travel speeds: 4.2/2.2 km/h for transport and preci
| Specifications | Value |
|---|---|
| No. | 1008048 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5960 |
| Bucket capacity (m³) | 0.09-0.23 |
| Boom length (mm) | 3000 |
| Rod length (mm) | 1600 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar 4TNV94L |
| Rated power (kw/rpm) | 39.8/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.054 |
| Ground specific pressure (Kpa) | 32.1 |
| Rotation speed (rpm) | 9.5 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 42.5 |
| Rod digging force (kN) | 28.5 |
| Travel speed (km/h) | 4.2/2.2 |
| Main overflow set pressure (Mpa) | 22 |
| Maximum flow of main pump (l/min) | 2*60.5+40.3+9.9 |
| Traveling Hydraulic Circuit (Mpa) | 22 |
| Rotary Hydraulic Circuit (Mpa) | 23 |
| Hydraulic crushing pipeline is standard | is |
| Main pump type | Rexroth |
| Pilot Oil Circuit (MPa) | 2.9 |
| Fuel Tank (L) | 110 |
| Hydraulic Tank (L) | 85 |
| Engine Oil changes (L) | 5.3 |
| Total transport length (mm) | 5850 |
| Total transport width (mm) | 1880/1920 |
| Total transport height (mm) | 2585 |
| Counterweight ground clearance (mm) | 694 |
| Minimum ground clearance (mm) | 369 |
| Minimum turning radius of front working device (mm) | 2450 |
| Back end turning radius (mm) | 1650 |
| Track gauge (mm) | 1480/1500 |
| Track plate width (mm) | 400 |
| Track ground length (mm) | 1985/1990 |
| Maximum digging radius (mm) | 6130 |
| Maximum digging depth (mm) | 3830 |
| Maximum excavation height (mm) | 5630 |
| Maximum unloading height (mm) | 3945 |
| Maximum vertical digging depth (mm) | 2680 |
| Dodging plate width × height (mm) | 1880*365/1920*340 |
