2023 XCMG XE60

1/5
Buy XCMG XE60 Used Excavator / 1
Buy XCMG XE60 Used Excavator / 2
Buy XCMG XE60 Used Excavator / 3
Buy XCMG XE60 Used Excavator / 4
Buy XCMG XE60 Used Excavator / 5

Product Description

This 2023 XCMG XE60 excavator, purchased in 2024, is now available from Sichuan, China. The XE60 is a reliable 6-ton class machine designed for versatility across construction, landscaping, and utility projects. XCMG's proven hydraulic system delivers consistent digging performance and fuel efficiency, making it suitable for contractors seeking dependable equipment with minimal operating hours.

  • Year of Manufacture: 2023
  • Model: XCMG XE60
  • Operating Weight: Approximately 6 tons
  • Location: Sichuan Province, China
  • Condition: Used, low hours
  • Application: General excavation, trenching, material handling

The XE60 combines compact dimensions with robust build quality, offering good maneuverability on confined job sites. Standard features include a comfortable operator cabin and straightforward maintenance access. This unit represents a cost-effective option for businesses expanding their fleet or replacing aging equipment.

SpecificationsValue
No.1073258
Tonnage (tons)6
Working weight (kg)5960
Bucket capacity (m³)0.09-0.23
Boom length (mm)3000
Rod length (mm)1600
Country of originXuzhou
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeYanmar 4TNV94L
Rated power (kw/rpm)39.8/2200
Cooling modewater-cooling
Number of cylinders (PCS)4
Displacement (L)3.054
Ground specific pressure (Kpa)32.1
Rotation speed (rpm)9.5
Climbing ability (%)35 °
Bucket digging force (kN)42.5
Rod digging force (kN)28.5
Travel speed (km/h)4.2/2.2
Main overflow set pressure (Mpa)22
Maximum flow of main pump (l/min)2*60.5+40.3+9.9
Traveling Hydraulic Circuit (Mpa)22
Rotary Hydraulic Circuit (Mpa)23
Hydraulic crushing pipeline is standardis
Main pump typeRexroth
Pilot Oil Circuit (MPa)2.9
Fuel Tank (L)110
Hydraulic Tank (L)85
Engine Oil changes (L)5.3
Total transport length (mm)5850
Total transport width (mm)1880/1920
Total transport height (mm)2585
Counterweight ground clearance (mm)694
Minimum ground clearance (mm)369
Minimum turning radius of front working device (mm)2450
Back end turning radius (mm)1650
Track gauge (mm)1480/1500
Track plate width (mm)400
Track ground length (mm)1985/1990
Maximum digging radius (mm)6130
Maximum digging depth (mm)3830
Maximum excavation height (mm)5630
Maximum unloading height (mm)3945
Maximum vertical digging depth (mm)2680
Dodging plate width × height (mm)1880*365/1920*340
see more

Overview

No.1073258

Brand Name:

XCMG

Model Number:

XE60

Year:

2023

Location:

Sichuan China

Pub Date
