Product Description
This 2020 XCMG XE60WA wheeled excavator is now available for sale from our Guangdong, China location. As a compact yet capable machine from one of China's leading construction equipment manufacturers, this unit offers versatility for urban construction, municipal projects, and material handling applications. The excavator comes equipped with a hydraulic breaker attachment and compact bucket, enhancing its utility for demolition and precision excavation work.
Key features include:
- Year of Manufacture: 2020
- Model: XCMG XE60WA Wheeled Excavator
- Includes hydraulic breaker attachment
- Compact bucket configuration for precise work
- Wheeled design for enhanced mobility and road travel
- Suitable for urban construction and municipal applications
- Currently located in Guangdong, China
Pricing is available upon request. Contact our sales team for detailed specifications, current condition assessment, and competitive pricing information for this well-maintained XCMG excavator.
| Specifications | Value |
|---|---|
| No. | 1054950 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5900 |
| Bucket capacity (m³) | 0.23 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | YANMAR 4TNV98-EXPXG |
| Rated power (kw/rpm) | 41.5/2400 |
| Total displacement (L) | 3.319 |
| Maximum torque (N.m) | 201/1800 |
| Forward speed (Km/h) | 26.4/10.5 |
| Rotation speed (rpm) | 8.5 |
| Climbing ability (%) | 56 |
| Bucket digging force (kN) | 42.8 |
| Rod digging force (kN) | 25.8 |
| Minimum turning radius (m) | 4.69 |
| Maximum flow of main pump (l/min) | 2 x 60 |
| Main pump type | Two plunger pumps |
| Working Hydraulic Circuit (Mpa) | 22 |
| Fuel Tank (L) | 110 |
| Hydraulic Tank (L) | 120 |
| Total transport length (mm) | 6230 |
| Total transport width (mm) | 1925 |
| Total transport height (mm) | 2850 |
| Counterweight ground clearance (mm) | 970 |
| Wheelbase (mm) | 2100 |
| Wheel base (mm) | 1600 |
| Minimum ground clearance (mm) | 290 |
| Back end turning radius (mm) | 1665 |
| Onboard width (mm) | 1925 |
| Maximum digging radius (mm) | 6120 |
| Maximum excavation radius (mm) | 5910 |
| Maximum digging depth (mm) | 3520 |
| Maximum excavation height (mm) | 5830 |
| Maximum unloading height (mm) | 4240 |
| Maximum vertical digging depth (mm) | 2400 |
| Maximum digging depth (mm) | 3520 |
| Dodging plate width × height (mm) | 390 (height) |
