Product Description
Discover the 2020 XCMG XE60WA, a robust and reliable heavy machine currently located in Hebei, China. This unit is equipped with a National III emission standard engine, ensuring it meets modern environmental regulations while delivering powerful performance. The machine's condition is impeccable, featuring its original paint, which speaks to its well-maintained history. The air conditioning system functions excellently, providing a comfortable working environment. Renowned for its efficiency and strength, the XE60WA is ready to tackle your most demanding projects. Trust in the durability and capability of this XCMG model to enhance your operational productivity.
- Year: 2020
- Brand: XCMG
- Model: XE60WA
- Location: Hebei, China
- Emission Standard: National III
- Condition: Excellent, with original paint
- Air Conditioning: Fully functional
| Specifications | Value |
|---|---|
| No. | 1115260 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5900 |
| Bucket capacity (m³) | 0.23 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | YANMAR 4TNV98-EXPXG |
| Rated power (kw/rpm) | 41.5/2400 |
| Total displacement (L) | 3.319 |
| Maximum torque (N.m) | 201/1800 |
| Forward speed (Km/h) | 26.4/10.5 |
| Rotation speed (rpm) | 8.5 |
| Climbing ability (%) | 56 |
| Bucket digging force (kN) | 42.8 |
| Rod digging force (kN) | 25.8 |
| Minimum turning radius (m) | 4.69 |
| Maximum flow of main pump (l/min) | 2 x 60 |
| Main pump type | Two plunger pumps |
| Working Hydraulic Circuit (Mpa) | 22 |
| Fuel Tank (L) | 110 |
| Hydraulic Tank (L) | 120 |
| Total transport length (mm) | 6230 |
| Total transport width (mm) | 1925 |
| Total transport height (mm) | 2850 |
| Counterweight ground clearance (mm) | 970 |
| Wheelbase (mm) | 2100 |
| Wheel base (mm) | 1600 |
| Minimum ground clearance (mm) | 290 |
| Back end turning radius (mm) | 1665 |
| Onboard width (mm) | 1925 |
| Maximum digging radius (mm) | 6120 |
| Maximum excavation radius (mm) | 5910 |
| Maximum digging depth (mm) | 3520 |
| Maximum excavation height (mm) | 5830 |
| Maximum unloading height (mm) | 4240 |
| Maximum vertical digging depth (mm) | 2400 |
| Maximum digging depth (mm) | 3520 |
| Dodging plate width × height (mm) | 390 (height) |
